Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 28 —
R954 1-249-437-11 CARBON 47K 5% 1/4W
R956 1-249-429-11 CARBON 10K 5% 1/4W
R957 1-249-429-11 CARBON 10K 5% 1/4W
R958 1-249-429-11 CARBON 10K 5% 1/4W
R959 1-249-429-11 CARBON 10K 5% 1/4W
R960 1-249-397-11 CARBON 22 5% 1/4W F
R961 1-249-397-11 CARBON 22 5% 1/4W F
R963 1-249-417-11 CARBON 1K 5% 1/4W F
R964 1-249-431-11 CARBON 15K 5% 1/4W
R965 1-249-441-11 CARBON 100K 5% 1/4W
! R970 1-217-156-00 WIREWOUND 0.22 10% 5W F
! R974 1-212-849-00 FUSIBLE 4.7 5% 1/4W F
************************************************************
* 1-666-060-11 AVIN BOARD
**********
< CAPACITOR >
C6301 1-162-286-31 CERAMIC 220PF 10% 50V
C6302 1-162-286-31 CERAMIC 220PF 10% 50V
C6303 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN6301 1-564-524-11 PLUG, CONNECTOR 9P
< DIODE >
D6300 8-719-987-63 DIODE 1N4148M
< JACK >
J6301 1-779-583-11 JACK, PIN 3P (AV INPUT)
< RESISTOR >
R6301 1-249-417-11 CARBON 1K 5% 1/4W F
R6302 1-249-417-11 CARBON 1K 5% 1/4W F
R6303 1-249-441-11 CARBON 100K 5% 1/4W
R6304 1-249-441-11 CARBON 100K 5% 1/4W
< RELAY >
RY6300 1-515-622-11 RELAY
************************************************************
* 1-666-062-11 JOG BOARD
**********
< DIODE >
D512 8-719-046-44 DIODE SEL5221S (ENTER/NEXT)
D513 8-719-046-44 DIODE SEL5221S (→)
D514 8-719-046-44 DIODE SEL5221S (←)
< RESISTOR >
R537 1-249-407-11 CARBON 150 5% 1/4W F
R538 1-249-401-11 CARBON 47 5% 1/4W F
R541 1-249-419-11 CARBON 1.5K 5% 1/4W F
R644 1-249-429-11 CARBON 10K 5% 1/4W
R645 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S534 1-762-751-11 SWITCH, TACTILE (ENTER/NEXT)
S536 1-762-874-11 SWITCH, JOG (MULTI JOG STATION)
************************************************************
* A-4403-202-A MAIN BOARD,COMPLETE
********************
< CAPACITOR >
C101 1-136-167-00 FILM 0.15uF 5% 50V
C102 1-130-471-00 MYLAR 0.001uF 5% 50V
C103 1-136-169-00 FILM 0.22uF 5% 50V
C104 1-136-169-00 FILM 0.22uF 5% 50V
C105 1-136-495-11 FILM 0.068uF 5% 50V
C106 1-136-495-11 FILM 0.068uF 5% 50V
C107 1-137-440-11 FILM 0.018uF 5% 50V
C108 1-137-440-11 FILM 0.018uF 5% 50V
C109 1-137-437-11 FILM 0.0056uF 5% 50V
C110 1-130-479-00 MYLAR 0.0047uF 5% 50V
C111 1-130-479-00 MYLAR 0.0047uF 5% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C113 1-126-963-11 ELECT 4.7uF 20% 50V
C114 1-136-166-00 FILM 0.12uF 5% 50V
C115 1-136-166-00 FILM 0.12uF 5% 50V
C116 1-126-961-11 ELECT 2.2uF 20% 50V
C117 1-162-306-11 CERAMIC 0.01uF 20% 16V
C118 1-126-964-11 ELECT 10uF 20% 50V
C120 1-126-959-11 ELECT 0.47uF 20% 50V
C123 1-126-963-11 ELECT 4.7uF 20% 50V
C129 1-162-294-31 CERAMIC 0.001uF 10% 50V
C130 1-164-159-11 CERAMIC 0.1uF 50V
C140 1-162-306-11 CERAMIC 0.01uF 20% 16V
C153 1-136-169-00 FILM 0.22uF 5% 50V
C154 1-136-169-00 FILM 0.22uF 5% 50V
C155 1-136-495-11 FILM 0.068uF 5% 50V
C156 1-136-495-11 FILM 0.068uF 5% 50V
C157 1-137-440-11 FILM 0.018uF 5% 50V
C158 1-137-440-11 FILM 0.018uF 5% 50V
C159 1-137-437-11 FILM 0.0056uF 5% 50V
C160 1-130-479-00 MYLAR 0.0047uF 5% 50V
C161 1-130-479-00 MYLAR 0.0047uF 5% 50V
C162 1-126-964-11 ELECT 10uF 20% 50V
C163 1-126-963-11 ELECT 4.7uF 20% 50V
C164 1-136-166-00 FILM 0.12uF 5% 50V
C165 1-136-166-00 FILM 0.12uF 5% 50V
C166 1-126-961-11 ELECT 2.2uF 20% 50V
C177 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-162-215-31 CERAMIC 47PF 5% 50V
C182 1-126-960-11 ELECT 1uF 20% 50V
C183 1-126-961-11 ELECT 2.2uF 20% 50V
C188 1-126-964-11 ELECT 10uF 20% 50V
C703 1-126-963-11 ELECT 4.7uF 20% 50V
C731 1-126-964-11 ELECT 10uF 20% 50V
C732 1-126-964-11 ELECT 10uF 20% 50V
C753 1-126-963-11 ELECT 4.7uF 20% 50V
C801 1-136-165-00 FILM 0.1uF 5% 50V
C802 1-136-165-00 FILM 0.1uF 5% 50V
C803 1-104-482-11 ELECT 4700uF 20% 63V
C804 1-104-482-11 ELECT 4700uF 20% 63V
AMP AVIN JOG MAIN
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
To Next Page
