Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 29 —
C807 1-126-964-11 ELECT 10uF 20% 50V
C808 1-126-948-11 ELECT 100uF 20% 35V
C831 1-126-942-61 ELECT 1000uF 20% 25V
C832 1-126-942-61 ELECT 1000uF 20% 25V
C835 1-136-165-00 FILM 0.1uF 5% 50V
C836 1-136-165-00 FILM 0.1uF 5% 50V
C852 1-126-923-11 ELECT 220uF 20% 10V
C853 1-126-933-11 ELECT 100uF 20% 10V
C858 1-104-664-11 ELECT 47uF 20% 25V
C859 1-126-961-11 ELECT 2.2uF 20% 50V
C861 1-164-159-11 CERAMIC 0.1uF 50V
C6100 1-162-284-31 CERAMIC 150PF 10% 50V
C6101 1-126-964-11 ELECT 10uF 20% 50V
C6102 1-162-290-31 CERAMIC 470PF 10% 50V
C6103 1-162-291-31 CERAMIC 560PF 10% 50V
C6104 1-249-429-11 CARBON 10K 5% 1/4W
C6106 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6107 1-164-159-11 CERAMIC 0.1uF 50V
C6108 1-164-159-11 CERAMIC 0.1uF 50V
C6109 1-136-495-11 FILM 0.068uF 5% 50V
C6110 1-136-495-11 FILM 0.068uF 5% 50V
C6111 1-136-495-11 FILM 0.068uF 5% 50V
C6112 1-162-286-31 CERAMIC 220PF 10% 50V
C6113 1-162-286-31 CERAMIC 220PF 10% 50V
C6114 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6115 1-164-159-11 CERAMIC 0.1uF 50V
C6116 1-126-967-11 ELECT 47uF 20% 10V
C6117 1-164-159-11 CERAMIC 0.1uF 50V
C6118 1-124-584-00 ELECT 100uF 20% 10V
C6119 1-126-964-11 ELECT 10uF 20% 50V
C6120 1-126-964-11 ELECT 10uF 20% 50V
C6121 1-126-964-11 ELECT 10uF 20% 50V
C6123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6125 1-249-429-11 CARBON 10K 5% 1/4W
< CONNECTOR >
CN103 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
CN105 1-774-336-11 SOCKET, CONNECTOR(PC BOARD) 14P
CN106 1-774-336-11 SOCKET, CONNECTOR(PC BOARD) 14P
* CN6002 1-568-937-11 PIN, CONNECTOR 10P
* CNP701 1-764-017-21 HOUSING,CONNECTOR(PC BOARD) 17P
< DIODE >
D101 8-719-987-63 DIODE 1N4148M
D102 8-719-987-63 DIODE 1N4148M
D702 8-719-024-99 DIODE 11ES2-NTA2B
D801 8-719-302-38 DIODE RBV-602-01
D804 8-719-934-22 DIODE HZS30-2L
D809 8-719-987-63 DIODE 1N4148M
D810 8-719-987-63 DIODE 1N4148M
D821 8-719-987-63 DIODE 1N4148M
D824 8-719-024-99 DIODE 11ES2-NTA2B
D831 8-719-024-99 DIODE 11ES2-NTA2B
D832 8-719-024-99 DIODE 11ES2-NTA2B
D833 8-719-024-99 DIODE 11ES2-NTA2B
D834 8-719-024-99 DIODE 11ES2-NTA2B
D840 8-719-987-63 DIODE 1N4148M
D841 8-719-987-63 DIODE 1N4148M
D844 8-719-024-99 DIODE 11ES2-NTA2B
D852 8-719-987-63 DIODE 1N4148M
D1021 8-719-987-63 DIODE 1N4148M
< TERMINAL >
* E801 1-537-738-21 TERMINAL, EARTH
< IC >
IC101 8-759-634-50 IC M5218AL
IC105 8-759-460-02 IC M62427FP-A
IC701 8-759-000-47 IC MC14051BCP
IC751 8-759-000-47 IC MC14051BCP
IC850 8-759-111-68 IC uPC1237HA
IC6003 8-759-370-84 IC M65847FP
IC6004 8-759-140-53 IC uPD4053BC
< JACK >
J701 1-770-614-11 JACK, PIN 4P (MD/VIDEO 1)
J901 1-779-379-11 JACK, PIN 2P (SUPER WOOFER/MONITOR)
< COIL >
L6100 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q111 8-729-119-78 TRANSISTOR 2SC403SP-51
Q112 8-729-119-78 TRANSISTOR 2SC403SP-51
Q161 8-729-119-78 TRANSISTOR 2SC403SP-51
Q162 8-729-119-78 TRANSISTOR 2SC403SP-51
Q190 8-729-900-63 TRANSISTOR DTA124ES
Q191 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q192 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q801 8-729-141-83 TRANSISTOR 2SB1094-LK
Q810 8-729-900-36 TRANSISTOR DTC124ES
Q856 8-729-900-36 TRANSISTOR DTC124ES
Q857 8-729-900-63 TRANSISTOR DTA124ES
Q2100 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q6001 8-729-119-78 TRANSISTOR 2SC403SP-51
Q6002 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R101 1-249-429-11 CARBON 10K 5% 1/4W
R102 1-249-429-11 CARBON 10K 5% 1/4W
R103 1-249-429-11 CARBON 10K 5% 1/4W
R104 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R108 1-247-897-11 CARBON 560K 5% 1/4W
R109 1-249-419-11 CARBON 1.5K 5% 1/4W F
R110 1-249-433-11 CARBON 22K 5% 1/4W
R111 1-249-441-11 CARBON 100K 5% 1/4W
R112 1-249-421-11 CARBON 2.2K 5% 1/4W F
R113 1-249-441-11 CARBON 100K 5% 1/4W
R115 1-249-439-11 CARBON 68K 5% 1/4W
R116 1-249-437-11 CARBON 47K 5% 1/4W
R117 1-247-903-00 CARBON 1M 5% 1/4W
R118 1-249-417-11 CARBON 1K 5% 1/4W F
R119 1-249-433-11 CARBON 22K 5% 1/4W
R120 1-249-437-11 CARBON 47K 5% 1/4W
R122 1-247-903-00 CARBON 1M 5% 1/4W
R123 1-249-431-11 CARBON 15K 5% 1/4W
R124 1-249-437-11 CARBON 47K 5% 1/4W
MAIN
