Sony STR-V5500 - MIC ECHO; PANEL; VOLUME

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 31 —
* A-4403-207-A MIC ECHO BOARD, COMPLETE
*************************
< CAPACITOR >
C6001 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6002 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6003 1-124-257-00 ELECT 2.2uF 20% 50V
C6004 1-124-257-00 ELECT 2.2uF 20% 50V
C6005 1-162-215-31 CERAMIC 47PF 5% 50V
C6006 1-162-290-31 CERAMIC 470PF 10% 50V
C6008 1-126-160-11 ELECT 1uF 20% 50V
C6009 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6010 1-136-495-11 FILM 0.068uF 5% 50V
C6011 1-104-664-11 ELECT 47uF 20% 25V
C6012 1-126-160-11 ELECT 1uF 20% 50V
C6013 1-126-160-11 ELECT 1uF 20% 50V
C6014 1-104-664-11 ELECT 47uF 20% 25V
C6015 1-124-250-11 ELECT 0.15uF 20% 50V
C6016 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C6017 1-136-495-11 FILM 0.068uF 5% 50V
C6018 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C6019 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6020 1-126-160-11 ELECT 1uF 20% 50V
C6021 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6023 1-162-215-31 CERAMIC 47PF 5% 50V
C6024 1-162-282-31 CERAMIC 100PF 10% 50V
C6025 1-124-257-00 ELECT 2.2uF 20% 50V
C6026 1-124-261-00 ELECT 10uF 20% 50V
C6027 1-124-261-00 ELECT 10uF 20% 50V
C6028 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6030 1-124-465-00 ELECT 0.47uF 20% 50V
C6032 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6033 1-162-306-11 CERAMIC 0.01uF 20% 16V
< DIODE >
D6001 8-719-987-63 DIODE 1N4148M
D6002 8-719-987-63 DIODE 1N4148M
D6003 8-719-987-63 DIODE 1N4148M
< TERMINAL >
* G6001 1-537-738-21 TERMINAL, EARTH
< IC >
IC6001 8-759-634-51 IC M5218AP
IC6002 8-759-450-96 IC M65850P
< JACK >
J6001 1-770-226-11 JACK (LARGE TYPE) (MIX MIC1)
J6002 1-750-733-11 JACK (LARGE TYPE) (MIX MIC2)
J6003 1-770-226-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R6001 1-249-429-11 CARBON 10K 5% 1/4W
R6002 1-249-429-11 CARBON 10K 5% 1/4W
R6003 1-249-417-11 CARBON 1K 5% 1/4W F
R6004 1-249-417-11 CARBON 1K 5% 1/4W F
R6005 1-249-417-11 CARBON 1K 5% 1/4W F
R6006 1-249-425-11 CARBON 4.7K 5% 1/4W F
R6007 1-249-433-11 CARBON 22K 5% 1/4W
R6008 1-249-433-11 CARBON 22K 5% 1/4W
R6009 1-249-433-11 CARBON 22K 5% 1/4W
R6010 1-247-881-00 CARBON 120K 5% 1/4W
R6011 1-249-437-11 CARBON 47K 5% 1/4W
R6012 1-249-433-11 CARBON 22K 5% 1/4W
R6013 1-249-433-11 CARBON 22K 5% 1/4W
R6014 1-249-433-11 CARBON 22K 5% 1/4W
R6015 1-249-417-11 CARBON 1K 5% 1/4W F
R6016 1-247-843-11 CARBON 3.3K 5% 1/4W
R6017 1-249-417-11 CARBON 1K 5% 1/4W F
R6018 1-247-881-00 CARBON 120K 5% 1/4W
R6019 1-247-807-31 CARBON 100 5% 1/4W
R6030 1-247-895-00 CARBON 470K 5% 1/4W
R6201 1-249-419-11 CARBON 1.5K 5% 1/4W F
R6202 1-249-418-11 CARBON 1.2K 5% 1/4W F
R6251 1-249-419-11 CARBON 1.5K 5% 1/4W F
R6252 1-249-418-11 CARBON 1.2K 5% 1/4W F
< VARIABLE RESISTOR >
RV6001 1-225-511-11 RES,VAR,CARBON 50K/50K
(MIC LEVEL/ECHO VOL)
************************************************************
* A-4403-204-A PANEL BOARD, COMPLETE
**********************
VOLUME BOARD
**************
* 4-932-810-11 CUSHION (FL)
* 4-986-870-01 HOLDER, FL TUBE
< CAPACITOR >
C501 1-164-159-11 CERAMIC 0.1uF 50V
C502 1-164-159-11 CERAMIC 0.1uF 50V
C503 1-162-203-31 CERAMIC 15PF 5% 50V
C504 1-162-205-31 CERAMIC 18PF 5% 50V
C505 1-126-964-11 ELECT 10uF 20% 50V
C506 1-137-399-11 FILM 0.1uF 5% 50V
C507 1-124-248-00 ELECT 22uF 20% 35V
C508 1-162-306-11 CERAMIC 0.01uF 20% 16V
C509 1-126-964-11 ELECT 10uF 20% 50V
C510 1-162-306-11 CERAMIC 0.01uF 20% 16V
C511 1-124-584-00 ELECT 100uF 20% 10V
C512 1-126-964-11 ELECT 10uF 20% 50V
C514 1-126-964-11 ELECT 10uF 20% 50V
C515 1-162-306-11 CERAMIC 0.01uF 20% 16V
C516 1-126-964-11 ELECT 10uF 20% 50V
MIC ECHO PANEL VOLUME
