Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 32 —
C517 1-137-374-11 FILM 0.047uF 5% 50V
C518 1-162-306-11 CERAMIC 0.01uF 20% 16V
C519 1-124-464-11 ELECT 0.22uF 20% 50V
C520 1-137-371-11 FILM 0.015uF 5% 50V
C521 1-124-463-00 ELECT 0.1uF 20% 50V
C522 1-164-159-11 CERAMIC 0.1uF 50V
C523 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C524 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C525 1-162-288-31 CERAMIC 330PF 10% 50V
C526 1-164-159-11 CERAMIC 0.1uF 50V
C527 1-164-159-11 CERAMIC 0.1uF 50V
C528 1-104-905-11 CAPACITOR 0.22F 5.5V
C544 1-162-306-11 CERAMIC 0.01uF 20% 16V
C545 1-162-306-11 CERAMIC 0.01uF 20% 16V
C546 1-162-306-11 CERAMIC 0.01uF 20% 16V
C549 1-162-284-31 CERAMIC 150PF 10% 50V
C550 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN501 1-774-342-11 PLUG, CONNECTOR (PC BOARD) 14P
CN502 1-774-342-11 PLUG, CONNECTOR (PC BOARD) 14P
< DIODE >
D505 8-719-032-86 DIODE SEL5420E (KEY CONTROL n)
D506 8-719-046-36 DIODE SEL5921A-TH15 (KEY CONTROL ˜)
D511 8-719-987-63 DIODE 1N4148M
D518 8-719-046-39 DIODE SEL5821A-TH15 (VCD)
D519 8-719-046-39 DIODE SEL5821A-TH15 (PBC)
D520 8-719-046-39 DIODE SEL5821A-TH15 (AUTO PBC)
D521 8-719-046-80 DIODE SML19416W-TP4 (MOVIE)
D522 8-719-046-39 DIODE SEL5821A-TH15 (DNR)
D523 8-719-046-80 DIODE SML19416W-TP4 (P FILE)
D524 8-719-046-80 DIODE SML19416W-TP4 (P FILE)
D525 8-719-046-80 DIODE SML19416W-TP4 (GAME)
D526 8-719-046-80 DIODE SML19416W-TP4 (GAME)
D527 8-719-046-80 DIODE SML19416W-TP4 (MOVIE)
D528 8-719-046-80 DIODE SML19416W-TP4 (MUSIC)
D529 8-719-046-39 DIODE SEL5821A-TH15 (CD)
D530 8-719-046-39 DIODE SEL5821A-TH15 (TUNER)
D531 8-719-046-39 DIODE SEL5821A-TH15 (TIMER)
D532 8-719-046-80 DIODE SML19416W-TP4 (MUSIC)
D533 8-719-046-39 DIODE SEL5821A-TH15 (EFFECT)
D534 8-719-046-44 DIODE SEL5221S (EFFECT ON/OFF)
D536 8-719-032-86 DIODE SEL5420E (TUNER BAND)
D537 8-719-032-86 DIODE SEL5420E (TUNER BAND)
D538 8-719-046-44 DIODE SEL5221S (GROOVE)
D539 8-719-046-44 DIODE SEL5221S (GROOVE)
D540 8-719-046-36 DIODE SEL5921A-TH15 (DBFB)
D541 8-719-046-36 DIODE SEL5921A-TH15 (DBFB)
D542 8-719-064-63 DIODE SELU5823A-TP15
D543 8-719-064-63 DIODE SELU5823A-TP15
D575 8-719-987-63 DIODE 1N4148M
D576 8-719-987-63 DIODE 1N4148M
D579 8-719-024-99 DIODE 11ES2-NTA2B
D580 8-719-987-63 DIODE 1N4148M
D581 8-719-987-63 DIODE 1N4148M
D582 8-719-014-73 DIODE UZP-5.6BC-TP
D583 8-719-024-99 DIODE 11ES2-NTA2B
D585 8-719-987-63 DIODE 1N4148M
D586 8-719-987-63 DIODE 1N4148M
D587 8-719-987-63 DIODE 1N4148M
D588 8-719-987-63 DIODE 1N4148M
D589 8-719-987-63 DIODE 1N4148M
< FILTER >
FL501 1-517-618-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-759-483-31 IC TMP87CM75F-6623
IC502 8-759-332-18 IC GP1U27XB
IC503 8-759-165-82 IC PST600E-T
IC504 8-759-372-64 IC M66313FP-200C
< COIL >
L502 1-408-074-00 INDUCTOR 56uH
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC403SP-51
Q502 8-729-422-57 TRANSISTOR UN4111
Q503 8-729-119-78 TRANSISTOR 2SC403SP-51
Q504 8-729-422-57 TRANSISTOR UN4111
Q505 8-729-422-57 TRANSISTOR UN4111
Q506 8-729-422-57 TRANSISTOR UN4111
Q507 8-729-422-57 TRANSISTOR UN4111
Q508 8-729-422-57 TRANSISTOR UN4111
Q509 8-729-422-57 TRANSISTOR UN4111
Q510 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R501 1-249-407-11 CARBON 150 5% 1/4W F
R502 1-249-409-11 CARBON 220 5% 1/4W F
R503 1-249-411-11 CARBON 330 5% 1/4W
R504 1-249-413-11 CARBON 470 5% 1/4W F
R505 1-249-415-11 CARBON 680 5% 1/4W F
R506 1-249-417-11 CARBON 1K 5% 1/4W F
R507 1-249-407-11 CARBON 150 5% 1/4W F
R508 1-249-411-11 CARBON 330 5% 1/4W
R511 1-249-407-11 CARBON 150 5% 1/4W F
R512 1-249-409-11 CARBON 220 5% 1/4W F
R513 1-249-411-11 CARBON 330 5% 1/4W
R514 1-249-413-11 CARBON 470 5% 1/4W F
R515 1-249-415-11 CARBON 680 5% 1/4W F
R516 1-249-417-11 CARBON 1K 5% 1/4W F
R517 1-249-419-11 CARBON 1.5K 5% 1/4W F
R518 1-249-421-11 CARBON 2.2K 5% 1/4W F
R519 1-247-843-11 CARBON 3.3K 5% 1/4W
R520 1-249-427-11 CARBON 6.8K 5% 1/4W F
R521 1-249-431-11 CARBON 15K 5% 1/4W
R522 1-249-437-11 CARBON 47K 5% 1/4W
R523 1-249-413-11 CARBON 470 5% 1/4W F
R524 1-249-415-11 CARBON 680 5% 1/4W F
R525 1-249-417-11 CARBON 1K 5% 1/4W F
R526 1-249-419-11 CARBON 1.5K 5% 1/4W F
R527 1-249-421-11 CARBON 2.2K 5% 1/4W F
R528 1-247-843-11 CARBON 3.3K 5% 1/4W
R529 1-249-427-11 CARBON 6.8K 5% 1/4W F
R530 1-249-431-11 CARBON 15K 5% 1/4W
R531 1-249-437-11 CARBON 47K 5% 1/4W
R532 1-249-409-11 CARBON 220 5% 1/4W F
PANEL VOLUME
