Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 36 —
* 1-666-060-11 AVIN BOARD
**********
< CAPACITOR >
C6301 1-162-286-31 CERAMIC 220PF 10% 50V
C6302 1-162-286-31 CERAMIC 220PF 10% 50V
C6303 1-162-306-11 CERAMIC 0.01uF 20% 16V
(EXCEPT IA)
< CONNECTOR >
CN6301 1-564-524-11 PLUG, CONNECTOR 9P (EXCEPT IA)
* CN6301 1-564-522-11 PLUG, CONNECTOR 7P (IA)
< DIODE >
D6300 8-719-987-63 DIODE 1N4148M
< JACK >
J6301 1-779-583-11 JACK, PIN 3P (AV INPUT(VIDEO2))
< RESISTOR >
R6301 1-249-417-11 CARBON 1K 5% 1/4W F
R6302 1-249-417-11 CARBON 1K 5% 1/4W F
R6303 1-249-441-11 CARBON 100K 5% 1/4W
R6304 1-249-441-11 CARBON 100K 5% 1/4W
< RELAY >
RY6300 1-515-622-11 RELAY
*************************************************************
* 1-666-062-11 JOG BOARD
*********
< DIODE >
D512 8-719-046-44 DIODE SEL5221S (ENTER NEXT)
D513 8-719-046-44 DIODE SEL5221S (n)
D514 8-719-046-44 DIODE SEL5221S (N)
< RESISTOR >
R537 1-249-407-11 CARBON 150 5% 1/4W F
R538 1-249-401-11 CARBON 47 5% 1/4W F
R541 1-249-419-11 CARBON 1.5K 5% 1/4W F
R644 1-249-429-11 CARBON 10K 5% 1/4W
R645 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S534 1-762-751-11 SWITCH, TACTILE (ENTER/NEXT)
S536 1-762-874-11 SWITCH, JOG (MULTI JOG STATION)
*************************************************************
* A-4403-284-A KEY-CON BOARD,COMPLETE (MY,SP,KR,CH)
***********************
* A-4403-700-A KEY-CON BOARD,COMPLETE (IA)
***********************
* A-4403-707-A KEY-CON BOARD,COMPLETE (TH)
***********************
< CAPACITOR >
C6100 1-162-284-31 CERAMIC 150PF 10% 50V
C6101 1-126-964-11 ELECT 10uF 20% 50V
C6102 1-162-290-31 CERAMIC 470PF 10% 50V
C6103 1-162-291-31 CERAMIC 560PF 10% 50V
C6104 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C6106 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6107 1-164-159-11 CERAMIC 0.1uF 50V
C6108 1-164-159-11 CERAMIC 0.1uF 50V
C6109 1-136-495-11 FILM 0.068uF 5% 50V
C6110 1-136-495-11 FILM 0.068uF 5% 50V
C6111 1-136-495-11 FILM 0.068uF 5% 50V
C6112 1-162-286-31 CERAMIC 220PF 10% 50V
C6113 1-162-286-31 CERAMIC 220PF 10% 50V
C6114 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6115 1-164-159-11 CERAMIC 0.1uF 50V
C6116 1-126-967-11 ELECT 47uF 20% 10V
C6117 1-164-159-11 CERAMIC 0.1uF 50V
C6118 1-124-584-00 ELECT 100uF 20% 10V
C6119 1-126-964-11 ELECT 10uF 20% 50V
C6120 1-126-964-11 ELECT 10uF 20% 50V
C6121 1-126-964-11 ELECT 10uF 20% 50V
C6123 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
* CN6101 1-573-827-11 CONNECTOR, BOARD TO BOARD 13P
< IC >
IC6003 8-759-370-84 IC M65847FP
IC6004 8-759-140-53 IC uPD4053BC
< COIL >
L6100 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q6001 8-729-620-05 TRANSISTOR 2SC2603-EF
Q6025 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R6100 1-249-429-11 CARBON 10K 5% 1/4W
R6101 1-247-807-31 CARBON 100 5% 1/4W
R6102 1-249-417-11 CARBON 1K 5% 1/4W F
R6103 1-249-433-11 CARBON 22K 5% 1/4W
R6104 1-249-429-11 CARBON 10K 5% 1/4W
R6105 1-249-431-11 CARBON 15K 5% 1/4W
R6106 1-249-424-11 CARBON 3.9K 5% 1/4W F
R6108 1-249-429-11 CARBON 10K 5% 1/4W
R6109 1-249-425-11 CARBON 4.7K 5% 1/4W F
R6110 1-249-429-11 CARBON 10K 5% 1/4W
AVIN JOG KEY-CON
