Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 45 —
* A-4398-997-A SUPPLY POWER BOARD,COMPLETE
(MY,SP,KR,CH)
*****************************
* A-4403-693-A SUPPLY POWER BOARD,COMPLETE (IA)
*****************************
* A-4403-215-A SUPPLY POWER BOARD,COMPLETE (TH)
*****************************
< CAPACITOR >
C809 1-104-664-11 ELECT 47uF 20% 25V
C811 1-126-933-11 ELECT 100uF 20% 16V
C812 1-104-664-11 ELECT 47uF 20% 25V
C813 1-126-967-11 ELECT 47uF 20% 10V
C816 1-104-664-11 ELECT 47uF 20% 25V
C817 1-126-933-11 ELECT 100uF 20% 10V
C818 1-104-664-11 ELECT 47uF 20% 25V
C819 1-126-967-11 ELECT 47uF 20% 10V
C820 1-126-967-11 ELECT 47uF 20% 50V
C831 1-126-974-11 ELECT 3300uF 20% 50V
C832 1-126-974-11 ELECT 3300uF 20% 50V
C835 1-136-165-00 FILM 0.1uF 5% 50V
C836 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN810 1-569-507-11 PIN, CONNECTOR 12P
< DIODE >
D802 8-719-028-23 DIODE D3SBA20-4101
D807 8-719-000-81 DIODE UZL-7L3
D808 8-719-933-50 DIODE HZS7C2L
D812 8-719-933-50 DIODE HZS7C2L
D813 8-719-001-57 DIODE UZL-11H3-TP
< TRANSISTOR >
Q802 8-729-209-15 TRANSISTOR 2SD2012
Q804 8-729-209-15 TRANSISTOR 2SD2012
Q805 8-729-141-83 TRANSISTOR 2SB1094-LK
Q806 8-729-209-15 TRANSISTOR 2SD2012
Q8004 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R805 1-249-421-11 CARBON 2.2K 5% 1/4W F
R807 1-249-417-11 CARBON 1K 5% 1/4W F
! R808 1-212-962-00 FUSIBLE 15 5% 1/2W F
R809 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R810 1-213-036-51 FUSIBLE 1 5% 1W F
! R811 1-212-962-00 FUSIBLE 15 5% 1/2W F
! R813 1-213-060-51 FUSIBLE 10 5% 1W F
R820 1-249-419-11 CARBON 1.5K 5% 1/4W F
R821 1-249-419-11 CARBON 1.5K 5% 1/4W F
! R830 1-216-446-00 METAL OXIDE 18 5% 2W F
(EXCEPT TH)
! R830 1-215-881-11 METAL OXIDE 15 5% 2W F
(TH)
! R831 1-216-446-00 METAL OXIDE 18 5% 2W F
(EXCEPT TH)
! R831 1-215-881-11 METAL OXIDE 15 5% 2W F
(TH)
! R832 1-216-446-00 METAL OXIDE 18 5% 2W F
(EXCEPT TH)
! R832 1-215-881-11 METAL OXIDE 15 5% 2W F
! R833 1-216-446-00 METAL OXIDE 18 5% 2W F
(EXCEPT TH)
! R833 1-215-881-11 METAL OXIDE 15 5% 2W F
(TH)
! R834 1-216-446-00 METAL OXIDE 18 5% 2W F
(EXCEPT TH)
! R834 1-215-881-11 METAL OXIDE 15 5% 2W F
(TH)
! R835 1-216-446-00 METAL OXIDE 18 5% 2W F
(EXCEPT TH)
! R835 1-215-881-11 METAL OXIDE 15 5% 2W F
(TH)
! R836 1-215-884-11 METAL OXIDE 47 5% 2W F
(EXCEPT TH)
! R836 1-215-885-00 METAL OXIDE 68 5% 2W F
(TH)
*************************************************************
* 1-666-071-11 SUR BOARD
**********
< CAPACITOR >
C601 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN601 1-564-506-11 PLUG, CONNECTOR 3P
CN6004 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
*************************************************************
MISCELLANEOUS
**************
6 1-233-545-21 ENCAPSULATED COMPONENT (TH)
6 1-233-546-21 ENCAPSULATED COMPONENT (EXCEPT TH)
! 12 1-751-326-31 CORD, POWER (TH)
! 12 1-769-079-21 CORD, POWER (KR)
! 12 1-777-071-21 CORD, POWER (MY,SP)
! 12 1-782-315-11 CORD, POWER (IA)
! 12 1-782-464-21 CORD, POWER (CH)
! 13 1-569-007-11 ADAPTOR, CONVERSION 2P (IA)
! 13 1-569-008-21 ADAPTOR, CONVERSION 2P (MY,SP)
M601 1-698-792-11 FAN, DC
! T901 1-431-363-11 TRANSFORMER, POWER
*************************************************************
**************
HARDWARE LIST
**************
#1 7-685-872-09 SCREW +BVTT 3X8 (S)
#2 7-685-881-09 SCREW +BVTT 4X8 (S)
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#5 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
SUPPLY POWER
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
SUR
To Next Page
