MAIN BOARD
BACK PANEL
4 claw
1 connector
(CN911)
1 connector
(CN601)
5 Remove the back
panel to direction
of arrow
A .
3 screw
(BV3
× 8)
2 five screws
(BV3
× 10)
2 three screws
(BV3
× 10)
A
3 Remove the main board
to direction of arrow
A .
1 two screws
(BV3
× 16)
2 four screws
(BVTT3
× 6)
A
