— 18 —
Ref. No. Part No. Description Remark
C713 1-124-910-11 ELECT 47uF 20% 50V
C714 1-126-365-51 ELECT 100uF 20% 63V
C715 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C716 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C717 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C718 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C719 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C720 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C721 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C722 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C801 1-117-394-12 ELECT 10000uF 20% 50V
C802 1-117-394-12 ELECT 10000uF 20% 50V
C803 1-117-395-11 ELECT 6200uF 20% 50V
C804 1-117-395-11 ELECT 6200uF 20% 50V
C805 1-136-880-11 FILM 2.2uF 10% 160V
C806 1-161-744-00 CERAMIC 0.01uF 400V
C807 1-136-153-00 FILM 0.01uF 5% 50V
C808 1-126-690-51 ELECT 1000uF 20% 25V
C809 1-126-103-11 ELECT 470uF 20% 16V
C1001 1-102-824-00 CERAMIC 470PF 5% 50V
C1002 1-102-824-00 CERAMIC 470PF 5% 50V
C1003 1-102-824-00 CERAMIC 470PF 5% 50V
C1004 1-102-824-00 CERAMIC 470PF 5% 50V
< CONNECTOR >
CN201 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN202 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN203 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
* CN204 1-568-828-11 SOCKET, CONNECTOR 9P
CN205 1-766-897-11 PIN, CONNECTOR (PC BOARD) 4P
CN206 1-564-505-11 PLUG, CONNECTOR 2P
CN501 1-564-505-11 PLUG, CONNECTOR 2P
CN601 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D501 8-719-401-63 DIODE MA3062M-TX
D502 8-719-800-76 DIODE 1SS226
D503 8-719-800-76 DIODE 1SS226
D504 8-719-800-76 DIODE 1SS226
D505 8-719-310-60 DIODE SEL1510C-C
D601 8-719-401-63 DIODE MA3062M-TX
D602 8-719-800-76 DIODE 1SS226
D603 8-719-800-76 DIODE 1SS226
D604 8-719-800-76 DIODE 1SS226
D605 8-719-310-60 DIODE SEL1510C-C
D701 8-719-801-78 DIODE 1SS184
D702 8-719-801-78 DIODE 1SS184
D703 8-719-801-78 DIODE 1SS184
D704 8-719-801-78 DIODE 1SS184
D705 8-719-801-78 DIODE 1SS184
D706 8-719-801-78 DIODE 1SS184
D707 8-719-801-78 DIODE 1SS184
D708 8-719-801-78 DIODE 1SS184
D801 8-719-302-38 DIODE RBV-602-01
D802 8-719-302-38 DIODE RBV-602-01
D803 8-719-200-82 DIODE 11ES2
D804 8-719-200-82 DIODE 11ES2
D805 8-719-200-82 DIODE 11ES2
D806 8-719-200-82 DIODE 11ES2
D807 8-719-200-82 DIODE 11ES2
< FUSE >
! F802 1-532-506-51 FUSE, TIME-LAG (6.3A/250V)
! F803 1-532-506-51 FUSE, TIME-LAG (6.3A/250V)
< FUSE HOLDER >
FH801 1-533-293-11 FUSE HOLDER
FH802 1-533-293-11 FUSE HOLDER
FH803 1-533-293-11 FUSE HOLDER
FH804 1-533-293-11 FUSE HOLDER
< IC >
IC701 8-759-111-68 IC uPC1237HA
IC801 8-759-231-53 IC TA7805S
< JACK >
J201 1-566-883-41 JACK, PIN 6P (TUNER, CD, AUX IN)
J202 1-566-882-41 JACK, PIN 4P (TAPE REC OUT, IN)
J203 1-566-882-41 JACK, PIN 4P (MD REC OUT, IN)
< COIL >
L501 1-411-766-11 COIL, AIR-CORE
L601 1-411-766-11 COIL, AIR-CORE
< TRANSISTOR >
Q501 8-729-620-17 TRANSISTOR 2SC2259-FG
Q502 8-729-216-22 TRANSISTOR 2SA1162-G
Q503 8-729-216-22 TRANSISTOR 2SA1162-G
Q504 8-729-230-49 TRANSISTOR 2SC2712-YG
Q505 8-729-216-31 TRANSISTOR 2SA1163-G
Q506 8-729-216-31 TRANSISTOR 2SA1163-G
Q507 8-729-232-69 TRANSISTOR 2SK208GR3
Q508 8-729-271-31 TRANSISTOR 2SC2713-G
Q509 8-729-140-96 TRANSISTOR 2SD774-34
Q510 8-729-104-18 TRANSISTOR 2SC3514-Q
Q511 8-729-104-91 TRANSISTOR 2SA1383
Q512 8-729-018-15 TRANSISTOR 2SK1529A-Y
Q513 8-729-018-17 TRANSISTOR 2SJ200A-Y
Q514 8-729-271-31 TRANSISTOR 2SC2713-G
Q601 8-729-620-17 TRANSISTOR 2SC2259-FG
Q602 8-729-216-22 TRANSISTOR 2SA1162-G
Q603 8-729-216-22 TRANSISTOR 2SA1162-G
Q604 8-729-230-49 TRANSISTOR 2SC2712-YG
Q605 8-729-216-31 TRANSISTOR 2SA1163-G
Q606 8-729-216-31 TRANSISTOR 2SA1163-G
Q607 8-729-232-69 TRANSISTOR 2SK208GR3
Q608 8-729-271-31 TRANSISTOR 2SC2713-G
Q609 8-729-140-96 TRANSISTOR 2SD774-34
Q610 8-729-104-18 TRANSISTOR 2SC3514-Q
Q611 8-729-104-91 TRANSISTOR 2SA1383
Q612 8-729-018-15 TRANSISTOR 2SK1529A-Y
Q613 8-729-018-17 TRANSISTOR 2SJ200A-Y
Q614 8-729-271-31 TRANSISTOR 2SC2713-G
Q701 8-729-201-53 TRANSISTOR 2SA1015-GR
Q702 8-729-421-22 TRANSISTOR UN2211
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
MAIN
