— 19 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q703 8-729-201-53 TRANSISTOR 2SA1015-GR
Q704 8-729-421-22 TRANSISTOR UN2211
Q705 8-729-201-53 TRANSISTOR 2SA1015-GR
Q706 8-729-421-22 TRANSISTOR UN2211
Q707 8-729-201-53 TRANSISTOR 2SA1015-GR
Q708 8-729-421-22 TRANSISTOR UN2211
Q709 8-729-201-53 TRANSISTOR 2SA1015-GR
Q710 8-729-421-22 TRANSISTOR UN2211
Q711 8-729-201-53 TRANSISTOR 2SA1015-GR
Q712 8-729-421-22 TRANSISTOR UN2211
Q713 8-729-216-31 TRANSISTOR 2SA1163-G
Q714 8-729-201-53 TRANSISTOR 2SA1015-GR
Q715 8-729-201-53 TRANSISTOR 2SA1015-GR
< RESISTOR >
R151 1-260-032-11 CARBON MELF 1M 2% 1/8W
R152 1-260-032-11 CARBON MELF 1M 2% 1/8W
R153 1-260-032-11 CARBON MELF 1M 2% 1/8W
R154 1-260-032-11 CARBON MELF 1M 2% 1/8W
R155 1-260-032-11 CARBON MELF 1M 2% 1/8W
R156 1-260-032-11 CARBON MELF 1M 2% 1/8W
R157 1-260-032-11 CARBON MELF 1M 2% 1/8W
R158 1-259-995-11 CARBON MELF 1K 2% 1/8W
R159 1-259-995-11 CARBON MELF 1K 2% 1/8W
R251 1-260-032-11 CARBON MELF 1M 2% 1/8W
R252 1-260-032-11 CARBON MELF 1M 2% 1/8W
R253 1-260-032-11 CARBON MELF 1M 2% 1/8W
R254 1-260-032-11 CARBON MELF 1M 2% 1/8W
R255 1-260-032-11 CARBON MELF 1M 2% 1/8W
R256 1-260-032-11 CARBON MELF 1M 2% 1/8W
R257 1-260-032-11 CARBON MELF 1M 2% 1/8W
R258 1-259-995-11 CARBON MELF 1K 2% 1/8W
R259 1-259-995-11 CARBON MELF 1K 2% 1/8W
R501 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R502 1-260-020-11 CARBON MELF 100K 2% 1/8W
R503 1-259-987-11 CARBON MELF 220 2% 1/8W
R504 1-259-987-11 CARBON MELF 220 2% 1/8W
R505 1-259-987-11 CARBON MELF 220 2% 1/8W
R506 1-260-002-11 CARBON MELF 3.3K 2% 1/8W
R507 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R508 1-247-235-00 CARBON 620 5% 1/3W
R509 1-249-496-11 CARBON 100K 5% 1/3W
R510 1-259-983-11 CARBON MELF 100 2% 1/8W
R511 1-259-987-11 CARBON MELF 220 2% 1/8W
R512 1-260-013-11 CARBON MELF 27K 2% 1/8W
R513 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R514 1-259-983-11 CARBON MELF 100 2% 1/8W
R515 1-259-997-11 CARBON MELF 1.5K 2% 1/8W
R516 1-259-995-11 CARBON MELF 1K 2% 1/8W
! R517 1-212-958-00 FUSIBLE 10 5% 1/2W F
! R518 1-212-958-00 FUSIBLE 10 5% 1/2W F
! R519 1-212-994-00 FUSIBLE 330 5% 1/2W F
! R520 1-212-974-00 FUSIBLE 47 5% 1/2W F
! R521 1-212-974-00 FUSIBLE 47 5% 1/2W F
! R522 1-208-602-11 WIREWOUND 0.22 10% 2W F
! R523 1-208-602-11 WIREWOUND 0.22 10% 2W F
R524 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R525 1-259-997-11 CARBON MELF 1.5K 2% 1/8W
R526 1-216-254-00 CARBON MELF 220K 2% 1/8W
R527 1-247-727-11 CARBON 10 5% 1/2W
! R528 1-212-958-00 FUSIBLE 10 5% 1/2W F
R529 1-249-798-11 CARBON 680 5% 1/2W
R530 1-259-984-11 CARBON MELF 120 2% 1/8W
R601 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R602 1-260-020-11 CARBON MELF 100K 2% 1/8W
R603 1-259-987-11 CARBON MELF 220 2% 1/8W
R604 1-259-987-11 CARBON MELF 220 2% 1/8W
R605 1-259-987-11 CARBON MELF 220 2% 1/8W
R606 1-260-002-11 CARBON MELF 3.3K 2% 1/8W
R607 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R608 1-247-235-00 CARBON 620 5% 1/3W
R609 1-249-496-11 CARBON 100K 5% 1/3W
R610 1-259-983-11 CARBON MELF 100 2% 1/8W
R611 1-259-987-11 CARBON MELF 220 2% 1/8W
R612 1-260-013-11 CARBON MELF 27K 2% 1/8W
R613 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R614 1-259-983-11 CARBON MELF 100 2% 1/8W
R615 1-259-997-11 CARBON MELF 1.5K 2% 1/8W
R616 1-259-995-11 CARBON MELF 1K 2% 1/8W
! R617 1-212-958-00 FUSIBLE 10 5% 1/2W F
! R618 1-212-958-00 FUSIBLE 10 5% 1/2W F
! R619 1-212-994-00 FUSIBLE 330 5% 1/2W F
! R620 1-212-974-00 FUSIBLE 47 5% 1/2W F
! R621 1-212-974-00 FUSIBLE 47 5% 1/2W F
! R622 1-208-602-11 WIREWOUND 0.22 10% 2W F
! R623 1-208-602-11 WIREWOUND 0.22 10% 2W F
R624 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R625 1-259-997-11 CARBON MELF 1.5K 2% 1/8W
R626 1-216-254-00 CARBON MELF 220K 2% 1/8W
R627 1-247-727-11 CARBON 10 5% 1/2W
! R628 1-212-958-00 FUSIBLE 10 5% 1/2W F
R629 1-249-798-11 CARBON 680 5% 1/2W
R630 1-259-984-11 CARBON MELF 120 2% 1/8W
R701 1-247-751-11 CARBON 820 5% 1/2W
R702 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R703 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R704 1-247-751-11 CARBON 820 5% 1/2W
R705 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R706 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R707 1-247-751-11 CARBON 820 5% 1/2W
R708 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R709 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R710 1-247-751-11 CARBON 820 5% 1/2W
R711 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R712 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R713 1-247-751-11 CARBON 820 5% 1/2W
R714 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R715 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R716 1-247-751-11 CARBON 820 5% 1/2W
R717 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R718 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R719 1-260-008-11 CARBON MELF 10K 2% 1/8W
R720 1-260-017-11 CARBON MELF 56K 2% 1/8W
R721 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R722 1-218-760-11 METAL GLAZE 220K 2% 1/10W
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
