— 20 —
D905 8-719-313-50 DIODE SEL6810A-TH12 (TAPE)
D906 8-719-313-50 DIODE SEL6810A-TH12 (MD)
D907 8-719-400-20 DIODE MA152WA
D908 8-719-801-78 DIODE 1SS184
D909 8-719-801-78 DIODE 1SS184
D910 8-719-801-78 DIODE 1SS184
D911 8-719-313-40 DIODE SEL1516W (POWER)
D912 8-719-200-82 DIODE 11ES2
D913 8-719-200-82 DIODE 11ES2
< IC >
IC901 8-759-440-61 IC TMP47C200BN-H371(Z)
IC902 8-759-188-67 IC X24C01P-S
IC903 8-759-635-63 IC M51943BSL
IC904 8-759-962-08 IC BA6208
< TRANSISTOR >
Q901 8-729-424-08 TRANSISTOR UN2111
Q902 8-729-424-08 TRANSISTOR UN2111
Q903 8-729-424-08 TRANSISTOR UN2111
Q904 8-729-424-08 TRANSISTOR UN2111
< RESISTOR >
R901 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R902 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R903 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R904 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R905 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R906 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R907 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R908 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R909 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R910 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R911 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R912 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R913 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R914 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R915 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R916 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R917 1-208-518-41 METAL GLAZE 22K 2% 1/10W
R918 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R919 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R920 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R921 1-208-425-41 METAL GLAZE 330 2% 1/10W
R922 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R923 1-208-764-11 METAL GLAZE 180 2% 1/10W
R924 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R925 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R926 1-216-295-91 CONDUCTOR, CHIP (2012)
R927 1-216-295-91 CONDUCTOR, CHIP (2012)
R928 1-216-295-91 CONDUCTOR, CHIP (2012)
R929 1-216-295-91 CONDUCTOR, CHIP (2012)
R930 1-216-295-91 CONDUCTOR, CHIP (2012)
R931 1-216-295-91 CONDUCTOR, CHIP (2012)
R932 1-216-295-91 CONDUCTOR, CHIP (2012)
R933 1-216-295-91 CONDUCTOR, CHIP (2012)
R934 1-216-295-91 CONDUCTOR, CHIP (2012)
R935 1-216-295-91 CONDUCTOR, CHIP (2012)
PANEL
MAIN
Ref. No. Part No. Description Remark
R723 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R724 1-208-810-11 METAL GLAZE 15K 2% 1/10W
R725 1-208-812-11 METAL GLAZE 18K 2% 1/10W
R726 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R727 1-247-751-11 CARBON 820 5% 1/2W
R728 1-208-462-41 METAL GLAZE 10K 2% 1/10W
R729 1-208-453-41 METAL GLAZE 4.7K 2% 1/10W
R730 1-249-665-11 CARBON 470 5% 1/2W
! R731 1-212-966-00 FUSIBLE 22 5% 1/2W F
! R801 1-212-958-00 FUSIBLE 10 5% 1/2W F
R802 1-208-518-41 METAL GLAZE 22K 2% 1/10W
! R803 1-212-942-00 FUSIBLE 2.2 5% 1/2W F
R1001 1-208-437-41 METAL GLAZE 1K 2% 1/10W
R1002 1-208-437-41 METAL GLAZE 1K 2% 1/10W
R1003 1-208-437-41 METAL GLAZE 1K 2% 1/10W
R1004 1-208-437-41 METAL GLAZE 1K 2% 1/10W
R1005 1-208-437-41 METAL GLAZE 1K 2% 1/10W
R1006 1-208-437-41 METAL GLAZE 1K 2% 1/10W
< VARIABLE RESISTOR >
RV501 1-237-457-21 RES, ADJ, CARBON 2K
RV601 1-237-457-21 RES, ADJ, CARBON 2K
< RELAY >
RY701 1-755-062-11 RELAY
RY702 1-755-062-11 RELAY
RY703 1-755-062-11 RELAY
RY704 1-755-062-11 RELAY
RY705 1-755-062-11 RELAY
RY706 1-755-062-11 RELAY
RY707 1-755-062-11 RELAY
RY708 1-515-920-11 RELAY (24V)
< TERMINAL >
TM201 1-537-530-21 TERMINAL BOARD (SPEAKER)
**************************************************************
* A-4392-951-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C901 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C902 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C903 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C904 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C905 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN901 1-568-852-11 SOCKET, CONNECTOR 9P
* CN903 1-568-823-11 SOCKET, CONNECTOR 4P
< DIODE >
D901 8-719-313-50 DIODE SEL6810A-TH12 (PHONO)
D902 8-719-313-50 DIODE SEL6810A-TH12 (TUNER)
D903 8-719-313-50 DIODE SEL6810A-TH12 (CD)
D904 8-719-313-50 DIODE SEL6810A-TH12 (AUX)
Ref. No. Part No. Description Remark
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
