Sony TA-FE570 - Front Panel Assy; Main Board

TA-FE370/FE570
5
3-3. FRONT PANEL ASSY
3-4. MAIN BOARD
5 two screws
(BVTP3
× 8)
6 four screws
(BVTP3 × 8)
3 screw
(BVTP3
× 8)
1 connector (CN811)
4 harness
1 connector (CN812)
2 wire (flat type) (15 core)
(CN815)
7 front panel assy
3 two screws
(BVTP3
× 8)
4 two screws
(BVTP3
× 8)
3 screw
(BVTP3
× 8)
3 three screws
(BVTP3
× 8)
5 MAIN board
2 connector (CN901)
1 connector (CN902)
