Sony TRINITRON BVM-8045QD User Manual

8-3
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
<CONNECTOR>
CN12 * 1-766-746-11 CONNECTOR, BOARD TO BOARD 12P
<DIODE>
D241 8-719-800-76 DIODE 1SS226
<FERRITE BEAD>
FB1 1-410-397-21 FERRITE 1.1µH
<FILTER>
FL101 1-239-384-11 FILTER, EMI
FL200 1-409-898-11 DELAY LINE
FL201 1-233-241-11 FILTER, LOW PASS
FL202 1-239-384-11 FILTER, EMI
FL203 1-233-242-11 FILTER, LOW PASS
FL204 1-239-183-11 FILTER, EMI
FL205 1-233-243-11 FILTER, LOW PASS
FL206 1-239-384-11 FILTER, EMI
<IC>
IC101 * 1-540-106-11 SOCKET, IC
IC101 8-741-602-21 HYB IC SBX1602A
IC102 8-759-035-87 IC SC7S00F
IC103 8-759-991-19 IC PST529CMT
IC141 8-759-086-98 IC TC74ACT04F-EL
IC142 8-759-086-98 IC TC74ACT04F-EL
IC143 8-759-035-93 IC SC7S32F
IC144 8-759-172-72 IC CXD8386AQ
IC145 8-759-036-25 IC MC74AC04M
IC181 8-759-925-72 IC SN74HC02ANS
IC182 8-759-008-48 IC MC74HC86F
IC183 8-759-007-80 IC MC74HC175F
IC201 8-752-357-63 IC CXD2308Q
IC202 8-759-929-26 IC TL431CPS
<TRANSISTOR>
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-101-11 TRANSISTOR 2SC2351-R2
Q103 8-729-101-11 TRANSISTOR 2SC2351-R2
Q104 8-729-216-22 TRANSISTOR 2SA1162-G
Q105 8-729-901-06 TRANSISTOR DTA144EK
Q141 8-729-122-63 TRANSISTOR 2SA1226-E4
Q142 8-729-122-63 TRANSISTOR 2SA1226-E4
Q143 8-729-122-63 TRANSISTOR 2SA1226-E4
Q144 8-729-122-63 TRANSISTOR 2SA1226-E4
Q145 8-729-122-63 TRANSISTOR 2SA1226-E4
Q146 8-729-122-63 TRANSISTOR 2SA1226-E4
Q147 8-729-122-63 TRANSISTOR 2SA1226-E4
Q148 8-729-122-63 TRANSISTOR 2SA1226-E4
Q149 8-729-122-63 TRANSISTOR 2SA1226-E4
Q150 8-729-122-63 TRANSISTOR 2SA1226-E4
Q151 8-729-122-63 TRANSISTOR 2SA1226-E4
Q152 8-729-122-63 TRANSISTOR 2SA1226-E4
Q153 8-729-122-63 TRANSISTOR 2SA1226-E4
Q154 8-729-122-63 TRANSISTOR 2SA1226-E4
Q155 8-729-122-63 TRANSISTOR 2SA1226-E4
Q156 8-729-122-63 TRANSISTOR 2SA1226-E4
Q157 8-729-122-63 TRANSISTOR 2SA1226-E4
Q158 8-729-122-63 TRANSISTOR 2SA1226-E4
Q159 8-729-122-63 TRANSISTOR 2SA1226-E4
Q160 8-729-122-63 TRANSISTOR 2SA1226-E4
Q161 8-729-122-63 TRANSISTOR 2SA1226-E4
Q162 8-729-122-63 TRANSISTOR 2SA1226-E4
Q181 1-801-806-11 TRANSISTOR DTC144EK-T146
Q182 1-801-806-11 TRANSISTOR DTC144EK-T146
Q183 8-729-122-63 TRANSISTOR 2SA1226-E4
Q201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-216-22 TRANSISTOR 2SA1162-G
Q203 8-729-216-22 TRANSISTOR 2SA1162-G
Q241 8-729-216-22 TRANSISTOR 2SA1162-G
Q242 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R101 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R102 1-218-753-11 METAL CHIP 110K 0.50% 1/10W
R103 1-216-699-11 METAL CHIP 100K 0.50% 1/10W
R104 1-216-073-00 RES,CHIP 10K 5% 1/10W
R105 1-216-295-91 SHORT 0
R106 1-216-073-00 RES,CHIP 10K 5% 1/10W
R107 1-216-073-00 RES,CHIP 10K 5% 1/10W
R108 1-216-073-00 RES,CHIP 10K 5% 1/10W
R109 1-216-073-00 RES,CHIP 10K 5% 1/10W
R110 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R111 1-216-033-00 RES,CHIP 220 5% 1/10W
R112 1-216-033-00 RES,CHIP 220 5% 1/10W
R113 1-216-023-00 RES,CHIP 82 5% 1/10W
R114 1-216-013-00 RES,CHIP 33 5% 1/10W
R115 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R116 1-216-023-00 RES,CHIP 82 5% 1/10W
R117 1-216-013-00 RES,CHIP 33 5% 1/10W
R118 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R119 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R120 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R121 1-216-064-00 RES,CHIP 4.3K 5% 1/10W
R122 1-216-049-91 RES,CHIP 1K 5% 1/10W
R123 1-216-073-00 RES,CHIP 10K 5% 1/10W
R124 1-216-081-00 RES,CHIP 22K 5% 1/10W
R125 1-216-049-91 RES,CHIP 1K 5% 1/10W
R126 1-216-049-91 RES,CHIP 1K 5% 1/10W
R130 1-216-049-91 RES,CHIP 1K 5% 1/10W
R131 1-216-049-91 RES,CHIP 1K 5% 1/10W
R132 1-216-049-91 RES,CHIP 1K 5% 1/10W
R133 1-216-049-91 RES,CHIP 1K 5% 1/10W
R134 1-216-049-91 RES,CHIP 1K 5% 1/10W
R135 1-216-049-91 RES,CHIP 1K 5% 1/10W
R136 1-216-049-91 RES,CHIP 1K 5% 1/10W
R137 1-216-049-91 RES,CHIP 1K 5% 1/10W
R138 1-216-049-91 RES,CHIP 1K 5% 1/10W
R139 1-216-049-91 RES,CHIP 1K 5% 1/10W
R141 1-216-025-91 RES,CHIP 100 5% 1/10W
R142 1-216-025-91 RES,CHIP 100 5% 1/10W
