Sony TRINITRON BVM-8045QD User Manual

8-4
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
R143 1-216-037-00 RES,CHIP 330 5% 1/10W
R144 1-216-025-91 RES,CHIP 100 5% 1/10W
R145 1-216-025-91 RES,CHIP 100 5% 1/10W
R146 1-216-037-00 RES,CHIP 330 5% 1/10W
R147 1-216-025-91 RES,CHIP 100 5% 1/10W
R148 1-216-025-91 RES,CHIP 100 5% 1/10W
R149 1-216-037-00 RES,CHIP 330 5% 1/10W
R150 1-216-025-91 RES,CHIP 100 5% 1/10W
R151 1-216-025-91 RES,CHIP 100 5% 1/10W
R152 1-216-037-00 RES,CHIP 330 5% 1/10W
R153 1-216-025-91 RES,CHIP 100 5% 1/10W
R154 1-216-025-91 RES,CHIP 100 5% 1/10W
R155 1-216-037-00 RES,CHIP 330 5% 1/10W
R156 1-216-025-91 RES,CHIP 100 5% 1/10W
R157 1-216-025-91 RES,CHIP 100 5% 1/10W
R158 1-216-037-00 RES,CHIP 330 5% 1/10W
R159 1-216-025-91 RES,CHIP 100 5% 1/10W
R160 1-216-025-91 RES,CHIP 100 5% 1/10W
R161 1-216-037-00 RES,CHIP 330 5% 1/10W
R162 1-216-025-91 RES,CHIP 100 5% 1/10W
R163 1-216-025-91 RES,CHIP 100 5% 1/10W
R164 1-216-037-00 RES,CHIP 330 5% 1/10W
R165 1-216-025-91 RES,CHIP 100 5% 1/10W
R166 1-216-025-91 RES,CHIP 100 5% 1/10W
R167 1-216-037-00 RES,CHIP 330 5% 1/10W
R168 1-216-025-91 RES,CHIP 100 5% 1/10W
R169 1-216-025-91 RES,CHIP 100 5% 1/10W
R170 1-216-037-00 RES,CHIP 330 5% 1/10W
R171 1-216-025-91 RES,CHIP 100 5% 1/10W
R172 1-216-025-91 RES,CHIP 100 5% 1/10W
R173 1-216-037-00 RES,CHIP 330 5% 1/10W
R174 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R175 1-216-049-91 RES,CHIP 1K 5% 1/10W
R181 1-216-049-91 RES,CHIP 1K 5% 1/10W
R183 1-216-073-00 RES,CHIP 10K 5% 1/10W
R184 1-216-073-00 RES,CHIP 10K 5% 1/10W
R185 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R186 1-216-049-91 RES,CHIP 1K 5% 1/10W
R187 1-216-049-91 RES,CHIP 1K 5% 1/10W
R188 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R201 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R202 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R203 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R204 1-216-049-91 RES,CHIP 1K 5% 1/10W
R205 1-216-049-91 RES,CHIP 1K 5% 1/10W
R206 1-216-049-91 RES,CHIP 1K 5% 1/10W
R207 1-216-049-91 RES,CHIP 1K 5% 1/10W
R211 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R213 1-216-641-11 METAL CHIP 390 0.50% 1/10W
R215 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R216 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R217 1-216-025-91 RES,CHIP 100 5% 1/10W
R220 1-216-049-91 RES,CHIP 1K 5% 1/10W
R221 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R223 1-216-641-11 METAL CHIP 390 0.50% 1/10W
R225 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R226 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R227 1-216-025-91 RES,CHIP 100 5% 1/10W
R230 1-216-049-91 RES,CHIP 1K 5% 1/10W
R231 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R233 1-216-641-11 METAL CHIP 390 0.50% 1/10W
R235 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R236 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R237 1-216-025-91 RES,CHIP 100 5% 1/10W
R240 1-216-049-91 RES,CHIP 1K 5% 1/10W
R241 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R242 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R243 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R244 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R245 1-216-643-11 METAL CHIP 470 0.50% 1/10W
<VARIABLE RESISTOR>
RV101 1-238-801-11 RES, ADJ, CERMET 5K
RV201 1-238-801-11 RES, ADJ, CERMET 5K
RV202 1-238-801-11 RES, ADJ, CERMET 5K
RV203 1-238-801-11 RES, ADJ, CERMET 5K
***************************************************************
* A-1135-964-A B COMPLETE (BVM-8045QD)
* A-1135-977-A B COMPLETE (BVM-9045D)
****************************
<BAND PASS FILTER>
BPF101 1-236-363-11 FILTER, BAND PASS
BPF102 1-236-364-11 FILTER, BAND PASS
<CAPACITOR>
C101 1-124-589-11 ELECT 47µF 20% 16V
C102 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C103 1-126-157-11 ELECT 10µF 20% 16V
C104 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C105 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C106 1-104-664-11 ELECT 47µF 20% 16V
C107 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C108 1-104-664-11 ELECT 47µF 20% 16V
C109 1-104-664-11 ELECT 47µF 20% 16V
C110 1-104-666-11 ELECT 220µF 20% 16V
C111 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C112 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C113 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C114 1-104-664-11 ELECT 47µF 20% 16V
C115 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C116 1-124-589-11 ELECT 47µF 20% 16V
C117 1-124-589-11 ELECT 47µF 20% 6.3V
C118 1-124-589-11 ELECT 47µF 20% 6.3V
C119 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C120 1-124-589-11 ELECT 47µF 20% 6.3V
C121 1-124-589-11 ELECT 47µF 20% 6.3V
C122 1-104-664-11 ELECT 47µF 20% 16V
C123 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C124 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C125 1-124-589-11 ELECT 47µF 20% 6.3V
