Sony TRINITRON BVM-8045QD User Manual

8-6
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
C248 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C249 1-104-665-11 ELECT 100µF 20% 16V
C250 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C251 1-110-364-11 MYLAR 0.1µF 10% 200V
C252 1-107-638-11 ELECT 33µF 20% 160V
C253 1-104-664-11 ELECT 47µF 20% 16V
C254 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C255 1-104-664-11 ELECT 47µF 20% 16V
C256 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C257 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C258 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C259 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C260 1-124-465-00 ELECT 0.47µF 20% 50V
C261 1-137-193-11 FILM 0.39µF 5% 50V
C262 1-124-465-00 ELECT 0.47µF 20% 50V
C264 1-163-123-00 CERAMIC CHIP 180PF 5% 50V
C265 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C266 1-107-714-11 ELECT 10µF 20% 16V
C267 1-107-714-11 ELECT 10µF 20% 16V
C268 1-104-664-11 ELECT 47µF 20% 16V
C269 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C270 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C271 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C272 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C273 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C274 1-104-664-11 ELECT 47µF 20% 16V
C275 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C277 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C278 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C279 1-126-157-11 ELECT 10µF 20% 16V
C280 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C281 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C282 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C283 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C299 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C300 1-126-157-11 ELECT 10µF 20% 16V
C301 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C302 1-124-589-11 ELECT 47µF 20% 16V
C303 1-126-157-11 ELECT 10µF 20% 16V
C304 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C305 1-117-378-11 FILM 1µF 5% 50V
C306 1-163-115-00 CERAMIC CHIP 82PF 5% 50V
C307 1-163-145-00 CERAMIC CHIP 0.0015µF 5% 50V
C308 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C309 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C310 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C312 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C313 1-163-115-00 CERAMIC CHIP 82PF 5% 50V
C314 1-126-157-11 ELECT 10µF 20% 16V
C315 1-164-299-11 CERAMIC CHIP 0.22µF 10% 25V
C316 1-126-157-11 ELECT 10µF 20% 16V
C317 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C318 1-163-095-00 CERAMIC CHIP 12PF 5% 50V
C319 1-163-095-00 CERAMIC CHIP 12PF 5% 50V
C320 1-163-095-00 CERAMIC CHIP 12PF 5% 50V
C321 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C322 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C324 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C340 1-163-205-00 CERAMIC CHIP 0.001µF 5% 50V
C344 1-163-092-00 CERAMIC CHIP 9PF 0.25PF 50V
C345 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C346 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C347 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C1293 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C1294 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C1295 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C1296 1-163-115-00 CERAMIC CHIP 82PF 5% 50V
C1297 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
C1298 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C1299 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C1300 1-126-160-11 ELECT 1µF 20% 50V
C1301 1-126-160-11 ELECT 1µF 20% 50V
C1302 1-126-160-11 ELECT 1µF 20% 50V
C1303 1-126-160-11 ELECT 1µF 20% 50V
C1400 1-163-141-00 CERAMIC CHIP 0.001µF 5% 50V
C1401 1-163-141-00 CERAMIC CHIP 0.001µF 5% 50V
C1402 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C1403 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1404 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
<FILTER BLOCK>
CFM101 1-464-880-11 FILTER BLOCK, COM (CFB-2)
<CONNECTOR>
CN101 1-506-480-11 PIN, CONNECTOR 15P
CN102 * 1-564-506-11 PLUG, CONNECTOR 3P
CN103 * 1-565-503-11 CONNECTOR, BOARD TO BOARD 12P
CN104 * 1-564-011-11 PIN, CONNECTOR 12P
CN105 * 1-564-509-11 PLUG, CONNECTOR 6P
CN106 1-506-473-11 PIN, CONNECTOR 8P
CN107 1-506-478-11 PIN, CONNECTOR 13P
CN108 * 1-564-506-11 PLUG, CONNECTOR 3P
<TRAP MODULE>
CTR101 1-236-366-11 MODULE, TRAP
CTR102 1-236-365-11 MODULE, TRAP
<DIODE>
D103 8-719-404-49 DIODE MA111
D104 8-719-404-49 DIODE MA111
D105 8-719-404-49 DIODE MA111
D106 8-719-404-49 DIODE MA111
D107 8-719-404-49 DIODE MA111
D108 8-719-404-49 DIODE MA111
D109 8-719-404-49 DIODE MA111
D110 8-719-404-49 DIODE MA111
D111 8-719-404-49 DIODE MA111
D112 8-719-404-49 DIODE MA111
D113 8-719-404-49 DIODE MA111
D117 8-719-404-49 DIODE MA111
D120 8-719-404-49 DIODE MA111
D121 8-719-404-49 DIODE MA111
D122 8-719-404-49 DIODE MA111
