Sony TRINITRON BVM-8045QD User Manual

8-7
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
D123 8-719-404-49 DIODE MA111
D125 8-719-404-49 DIODE MA111
D126 8-719-404-49 DIODE MA111
D127 8-719-404-49 DIODE MA111
D128 8-719-801-78 DIODE 1SS184
D129 8-719-404-49 DIODE MA111
D130 8-719-800-76 DIODE 1SS226
D131 8-719-800-76 DIODE 1SS226
D132 8-719-800-76 DIODE 1SS226
D133 8-719-404-49 DIODE MA111
D134 8-719-404-49 DIODE MA111
D135 8-719-404-49 DIODE MA111
D136 8-719-404-49 DIODE MA111
D137 8-719-404-49 DIODE MA111
D138 8-719-404-49 DIODE MA111
D139 8-719-404-49 DIODE MA111
D144 8-719-404-49 DIODE MA111
D145 8-719-404-49 DIODE MA111
D146 8-719-404-49 DIODE MA111
D147 8-719-404-49 DIODE MA111
D148 8-719-404-49 DIODE MA111
D149 8-719-404-49 DIODE MA111
D150 8-719-404-49 DIODE MA111
D151 8-719-404-49 DIODE MA111
D152 8-719-404-49 DIODE MA111
D153 8-719-977-20 DIODE DTZ8.2B
D154 8-719-404-49 DIODE MA111
D155 8-719-404-49 DIODE MA111
D156 8-719-404-49 DIODE MA111
D157 8-719-901-83 DIODE 1SS83
D158 8-719-901-83 DIODE 1SS83
D159 8-719-901-83 DIODE 1SS83
D160 8-719-404-49 DIODE MA111
D161 8-719-404-49 DIODE MA111
D162 8-719-404-49 DIODE MA111
D170 8-719-404-49 DIODE MA111
D185 8-719-104-34 DIODE 1S2836
D186 8-719-801-78 DIODE 1SS184
D187 8-719-800-76 DIODE 1SS226
D188 8-719-800-76 DIODE 1SS226
D191 8-719-104-34 DIODE 1S2836
D285 8-719-404-49 DIODE MA111
D289 8-719-404-49 DIODE MA111
D341 8-719-404-49 DIODE MA111
D342 8-719-104-34 DIODE 1S2836
D343 8-719-800-76 DIODE 1SS226
D344 8-719-105-99 DIODE RD6.2M-B1
D345 8-719-901-83 DIODE 1SS83
D346 8-719-901-83 DIODE 1SS83
D347 8-719-901-83 DIODE 1SS83
D348 8-719-800-76 DIODE 1SS226
D349 8-719-800-76 DIODE 1SS226
D350 8-719-800-76 DIODE 1SS226
D390 8-719-800-76 DIODE 1SS226
D393 8-719-404-49 DIODE MA111
D1400 8-719-045-70 DIODE 1SV230TPH3
D1401 8-719-404-49 DIODE MA111
<DELAY LINE>
DL101 1-415-632-11 DELAY LINE, Y
DL102 1-415-633-11 DELAY LINE, Y
<IC>
IC101 8-759-432-78 IC MM1111XFBE
IC102 8-759-446-66 IC MM1113XFBE
IC103 8-759-446-66 IC MM1113XFBE
IC104 8-759-446-66 IC MM1113XFBE
IC105 8-759-432-78 IC MM1111XFBE
IC106 8-759-009-51 IC MC14538BF
IC107 8-759-473-08 IC BU4584BF-E2
IC108 8-759-932-67 IC BU4053BCF
IC109 8-759-473-07 IC BU4070BF-E2
IC110 8-759-932-67 IC BU4053BCF
IC111 8-759-932-67 IC BU4053BCF
IC112 8-759-231-53 IC TA7805S
IC113 8-759-631-08 IC M51279FP
IC114 8-759-208-09 IC TC4052BFHB
IC115 8-759-208-09 IC TC4052BFHB
IC116 8-759-008-67 IC MC14066BF
IC117 8-759-358-46 IC MM1114XFBE
IC118 8-759-358-46 IC MM1114XFBE
IC119 8-759-358-46 IC MM1114XFBE
IC120 8-759-008-67 IC MC14066BF
IC121 8-759-932-67 IC BU4053BCF
IC122 8-759-998-98 IC LM358D
IC123 8-759-998-98 IC LM358D
IC124 8-752-052-62 IC CXA1478S
IC125 8-759-008-67 IC MC14066BF
IC126 8-759-932-67 IC BU4053BCF
IC127 8-759-998-98 IC LM358D
IC128 8-759-998-98 IC LM358D
IC129 8-759-998-98 IC LM358D
IC1400 8-759-242-64 IC TC4W53F
IC1401 8-759-209-97 IC TC4S81F
<CHIP CONDUCTOR>
JR105 1-216-295-91 SHORT 0
JR110 1-216-295-91 SHORT 0
JR133 1-216-295-91 SHORT 0
JR138 1-216-295-91 SHORT 0
JR178 1-216-295-91 SHORT 0
<COIL>
L101 1-410-470-11 INDUCTOR 10µH
L102 1-410-090-41 INDUCTOR 18mH
L103 1-412-002-31 INDUCTOR CHIP 4.7µH
L104 1-412-002-31 INDUCTOR CHIP 4.7µH
L105 1-412-002-31 INDUCTOR CHIP 4.7µH
L106 1-410-470-11 INDUCTOR 10µH
L107 1-410-470-11 INDUCTOR 10µH
L112 1-408-613-31 INDUCTOR 68µH
L113 1-410-947-31 INDUCTOR CHIP 33µH
L114 1-410-947-31 INDUCTOR CHIP 33µH
