The parts on this page belong to the following model(s) only:
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 93 —
V SERIES
BOARD VARIANT PARTS LIST
A
KV-35V65CND/37VL65/37VL65C
A BOARD VARIANT LIST:
KV-35V65CND/37VL65/37VL65C
* A-1298-647-A A BOARD, COMPLETE
CAPACITOR
C069 1-126-964-11 ELECT 10MF 20% 50V
C461 1-126-964-11 ELECT 10MF 20% 50V
C478 1-126-934-11 ELECT 220MF 20% 16V
C479 1-126-964-11 ELECT 10MF 20% 50V
C513 ¡ 1-129-720-00 FILM 0.033MF 5% 630V
C514 ¡ 1-136-540-11 FILM 0.82MF 5% 200V
C520 1-101-821-00 CERAMIC CHIP 0.0022MF 500V
C521 1-164-182-11 CERAMIC CHIP 0.0033MF 10% 50V
C537 1-126-942-61 ELECT 1000MF 20% 25V
C539 ¡ 1-126-942-61 ELECT 1000MF 20% 25V
C542 1-106-383-00 MYLAR 0.047MF 10% 200V
CONNECTOR
CN461 1-564-508-11 PLUG, CONNECTOR 5P
CN1101 1-573-298-11 CONNECTOR, BOARD TO BOARD
CN3001 1-573-298-11 CONNECTOR, BOARD TO BOARD
DIODE
D368 8-719-991-33 DIODE 1SS133T-77
CHIP CONDUCTOR
JR001 1-216-295-91 SHORT
JR201 1-216-295-91 SHORT
JR202 1-216-295-91 SHORT
JR463 1-216-295-91 SHORT
COIL
L461 1-408-617-31 INDUCTOR 180UH
L541 1-406-677-11 INDUCTOR
TRANSISTOR
Q1103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R006 1-247-815-91 CARBON 220 5% 1/4W
R008 1-247-815-91 CARBON 220 5% 1/4W
R012 1-216-033-00 RES,CHIP 220 5% 1/10W
R031 1-247-815-91 CARBON 220 5% 1/4W
R040 1-247-815-91 CARBON 220 5% 1/4W
R041 1-216-065-91 “RES,CHIP” 4.7K 5% 1/10W
R042 1-216-065-91 “RES,CHIP” 4.7K 5% 1/10W
R045 1-247-815-91 CARBON 220 5% 1/4W
R069 1-216-073-00 RES,CHIP 10K 5% 1/10W
R085 1-216-073-00 RES,CHIP 10K 5% 1/10W
R088 1-216-033-00 RES,CHIP 220 5% 1/10W
R090 1-216-033-00 RES,CHIP 220 5% 1/10W
R358 1-247-815-91 CARBON 220 5% 1/4W
R359 1-247-815-91 CARBON 220 5% 1/4W
R360 1-247-815-91 CARBON 220 5% 1/4W
R386 1-216-049-91 RES,CHIP 1K 5% 1/10W
R511 ¡ 1-215-886-11 METAL 100 5% 2W
R515 1-216-077-00 RES, CHIP 15K 5% 1/10W
R523 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R529 1-208-812-11 RES,CHIP 18K 0.50% 1/10W
R531 ¡ 1-208-838-11 RES,CHIP 220K 0.50% 1/10W
R533 ¡ 1-215-878-00 METAL 33K 5% 1W
R541 1-249-377-11 CARBON 0.47 5% 1/4W
R542 1-249-397-11 CARBON 22 5% 1/4W
R546 1-215-451-00 METAL 18K 1% 1/4W
TRANSFORMER
T502 ¡ 1-429-408-11 TRANSFORMER FERRITE (PMT)
T503 ¡ X-4034-797-1 FLYBACK TRANSFORMER ASSY, NX-3005//J1C
T504 1-413-059-00 TRANSFORMER FERRITE (DFT)
Note:
The components identified by
[
in this
manual have been carefully factory-selected
for each set in order to satisfy regulations re-
garding X-ray radiation. Should replacement
be required, replace only with the value origi-
nally used.
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
[
To Next Page
