Sony Trinitron KV-35V65 - COMPLETE PARTS LISTING WB

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 113 —
COMPLETE PARTS LISTING
WB
*A-1372-508-A WB BOARD, COMPLETE
(KV-32V40/34VL65C/32V65CND/34VL65/32S40/
34SL40/34SL40C/32S45/34SL45 only)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C2941 1-126-935-11 ELECT 470MF 20% 16V
C2944 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C2946 1-126-933-11 ELECT 100MF 20% 16V
C2949 1-161-830-00 CERAMIC CHIP 0.0047MF 500V
C2950 1-126-933-11 ELECT 100MF 20% 16V
C2951 1-107-638-11 ELECT 33MF 20% 160V
C2952 1-104-999-11 MYLAR 0.1MF 10% 200V
C2953 1-106-383-00 MYLAR 0.047MF 10% 200V
C2954 1-137-364-11 FILM 0.001MF 5% 50V
C2955 1-107-667-11 ELECT 2.2MF 20% 160V
C2956 1-137-364-11 FILM 0.001MF 5% 50V
C2957 1-106-383-00 MYLAR 0.047MF 10% 200V
C2958 1-126-933-11 ELECT 100MF 20% 16V
C2975 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
CONNECTOR
CN2941* 1-564-508-11 PLUG, CONNECTOR 5P
DIODE
D2941 8-719-991-33 DIODE 1SS133T-77
D2946 8-719-110-88 DIODE RD39ESB2
D2947 8-719-110-88 DIODE RD39ESB2
COIL
L2942 1-215-863-11 METAL OXIDE 100 5% 1W F
TRANSISTOR
Q2943 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2944 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2945 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2946 8-729-017-05 TRANSISTOR 2SA1837
Q2947 8-729-017-06 TRANSISTOR 2SC4793
Q2965 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2966 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R2943 1-216-025-91 RES,CHIP 100 5% 1/10W
R2948 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2949 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2950 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2951 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2952 1-216-037-00 RES,CHIP 330 5% 1/10W
R2953 1-216-021-00 RES,CHIP 68 5% 1/10W
R2954 1-216-033-00 RES,CHIP 220 5% 1/10W
R2955 1-216-047-91 RES,CHIP 820 5% 1/10W
R2956 1-216-295-91 SHORT
R2957 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2958 1-216-295-91 SHORT
R2959 1-216-021-00 RES,CHIP 68 5% 1/10W
R2979 1-216-017-91 RES,CHIP 47 5% 1/10W
R4941 1-260-311-11 CARBON 39 5% 1/2W
R4942 1-249-384-11 CARBON 1.8 5% 1/4W F
R4943 1-249-414-11 CARBON 560 5% 1/4W F
R4944 1-249-432-11 CARBON 18K 5% 1/4W
R4945 1-216-476-11 METAL OXIDE 180 5% 3W F
R4946 1-249-417-11 CARBON 1K 5% 1/4W F
R4947 1-249-432-11 CARBON 18K 5% 1/4W
R4948 1-249-414-11 CARBON 560 5% 1/4W
R4949 1-249-384-11 CARBON 1.8 5% 1/4W F
R4950 1-249-400-11 CARBON 39 5% 1/4W F
WB
