KV-42DRC700
1-1. REAR COVER REMOVAL
1-2. CHASSIS ASSEMBLY REMOVAL 1-3. SERVICE POSITION
SECTION 1: DISASSEMBLY
2
1
1
1
CAUTION! - Heat sink on IC5004 is -15V. Care must be
taken not to allow heat sink to touch any other components.
2
Gently pull the chassis assembly away from the bezel.
1
Pull up and rotate both the A and D Boards in order to
service the unit.
Remove 22 (+BVTP 4x16) screws from areas
indicated with a circle or line.
Chassis
Assembly
