– 37 –
KV-PG21P40/PG21M70/PG21P70
RM-952
CV BOARD VOLTAGE LIST
Ref Pin No Voltage[v]
J701 G2 (135) [142]
G1-1 0
H1 0
H2 0
G1-2 0
KB 133
KG (125) [145]
KR 129
G1-3 0
E0
Q705 B 8.9
C (144) [148]
E8.3
Q704 B 8.9
C 137
E8.3
Q706 B 8.9
C (128) [132]
E8.3
Q707 B 136
C7.6
E 132
Q708 B (143) [146]
C7.0
E 144
Q709 B (127) [131]
C7.0
E 128
Q710 B 2.5
C8.3
E1.8
Q711 B 2.3
C8.3
E1.6
Q712 B 2.6
C8.3
E1.9
Q1763 B 0
C0
E0
Q1765 B 0
C0
E0
Q1767 B 0
C0
E0
Q1777 B 0
C0
E0

Sony TRINITRON KV-PG21P40 Specifications

General

Screen Size	21 inches
Display Type	CRT
Aspect Ratio	4:3
Audio Output	Mono
Screen Type	Flat
Remote Control	Yes
Input/Output Connectors	Composite Video, RF, S-Video
Resolution (Lines)	500
Input Ports	RF
Audio Output Power	5W + 5W
