Sony Trinitron PVM-14L4 Service Manual

2-7,
2-8.
2-9,
2-10,
2-41,
2-12,
2-13.
2-14,
2-15.
2-16
Convergence Adjustment (1) ....
Deflection Yoke Neck Rotation Adjustment
Convergence Adjustment (2) ..
G2 Adjustment ...
White Balance Adjustment .....
Blue-only White Balance Adjustment ...
SUB BRIGHT, SUB CONTRAST Adjustment (15 K)
SUB BRIGHT, SUB CONTRAST Adjustment (33 K)
White Balance Interference Correction Adjustment
2-15-1. NTSC Composite Adjustment...
2-15-2, PAL Composite Adjustment
2-15-3. COMPONENT Adjustment ..
2-15-4, SDI Adjustment.
2-15-5. HD and SDI Adjustments.
Focus Adjustment...
3. Electrical Adjustments
3-1.
3-2.
3-3.
Equipment Required...
B Board Adjustments ..
3-2-1. Preparations
3-2-2, 15k YPBPR SMPTE (601) Signal Adjustment
3-2-2-1, Black Level Adjustment...
3-2-2-2, CHROMA Leak Adjustment
3-2-2-3. MATRIX Adjustment
3-2-3. 15k YPBPR BETACAM SETUP.
0 Signal Adjustment
3-2-4. 15k YPBPR BETACAM SETUP
7.5 Signal Adjustment
3-2-5. 33k YPBPR SMPTE (709) Signai Adjustment
{Applicable for PYM-D14L5J/D20L5I/14L5/20L5 only)
B1 Board Adjustments
3-3-1. Preparation
3-3-2. Y OUT Level Adjustment (BYPASS Mode)
3-3-3. Clamp Pulse Width Adjustment (NTSC)...
3-3-4. Burst Gate Pulse Width Adjustment (NTSC)
3-3-5. 3.58 FO Adjustment (NTSC)...
3-3-6. Phase Adjustment (NTSC)
3-3-7, Level Adjustment (NTSC)
3-3-8. Burst Gate Pulse Width Adjustment (PAL)
3-3-9, 4.43 FO Adjustment (PAL)
3-3-10, PAL B-Y Phase Adjustment
3-3-1. PAL Phase Adjustment (Normal)
3-3-12, Level Adjustment (PAL).......
3-3-13. Level Adjustment (NTSC 443) .....
PVM-14L9/14L4/2014
