4
Be sure to connect the AC power cord to a
grounded outlet.
Important safeguards/notices for use in the
medical environments
1
All the equipments connected to this unit shall be
certified according to Standard IEC601-1, IEC950,
IEC65 or other IEC/ISO Standards applicable to
the equipments.
2
When this unit is used together with other
equipment in the patient area*, the equipment shall
be either powered by an isolation transformer or
connected via an additional protective earth
terminal to system ground unless it is certified
according to Standard IEC601-1 and IEC601-1-1.
* Patient Area
3
The leakage current could increase when
connected to other equipment.
4
The operator should take precautions to avoid
touching the rear panel input and output circuitry
and the patient at the same time.
5
Model PVM-14N5MDE is a video monitor
intended for use in a medical environment to
display video pictures from cameras or other video
system.
5
Fine pitch Trinitron
1)
picture tube
The fine pitch Trinitron tube provides a high resolution
picture. Horizontal resolution is more than 500 TV
lines at the center of the picture.
Comb filter
When NTSC video signals are received, a comb filter
activates to make more accurate Y/C separation. This
contributes to less of a decrease in resolution, cross
color and cross luminance phenomena.
Beam current feedback circuit
The built-in beam current feedback circuit assures
stable white balance.
Four color system available
The monitor can display NTSC, PAL, SECAM and
NTSC
4.43
2)
signals. The appropriate color system is
selected automatically.
Input
Y/C input connectors
The video signal, split into the chrominance signal (C)
and the luminance signal (Y), can be input through this
connector, eliminating the interference between the
two signals, which tends to occur in a composite video
signal, ensuring video quality.
Automatic termination
(connector with
mark only)
The input connector is terminated at 75 ohms inside
when no cable is connected to the loop-through output
connector. When a cable is connected to an output
connector, the 75-ohm termination is automatically
released.
Features
Functions
On-screen menus
You can set monitor operation settings by using the
on-screen menus.
EIA standard 19-inch rack mounting
By using an MB-502B mounting bracket (not
supplied), the monitor can be mounted in an EIA
standard 19-inch rack.
For details on mounting, refer to the instruction manuals
supplied with the mounting bracket kit.
Side covers
The monitor can be covered with side covers. The side
covers that protect the ventilation holes from splashes
(of medicines, etc.) as much as possible.
1) Trinitron
“Trinitron” is a registered trademark of Sony Corporation.
2) NTSC
4.43
The NTSC
4.43
system refers to an NTSC color system in which the subcarrier frequency is modified to 4.43MHz. When an
NTSC recorded video program is played back with a Trident (PAL/SECAM/NTSC
4.43
) VTR, the NTSC
4.43
signal is output.
..........................................................................................................................................................................................................
