3-2
SIIA Chassis
3. Exiting the Service Mode
To exit the service mode, switch to the raster center
adjustment mode, and press the [ENTER] and [MENU]
keys simultaneously.
4. Moving to the Desired Service Item
To go back to a previous service item, use the [MENU] +
[(] keys. To forward to a service item in front, use the
[MENU] + [)] keys. Pressing these keys continuously
will move the cursor continuously.
5. Changing the Service Data
The adjustment data increases when the [(] key is pressed
and decreases when the [)] key is pressed. Pressing these
keys continuously will increase or decrease the value
continuously.
6. Writing the Service Data
To write the data from the RAM to the EEPROM, press
the [MENU] and [ENTER] keys once, check that SAVE
is displayed at Guidance, and then press the [MENU] and
[ENTER] keys again. Take note that when SAVE≥≥ is
displayed at Guidance, the items displayed as well as all
data will be written.
7. Setting the Raster Centering Adjustment
Mode
Press the [ENTER] key another time in the service mode.
Service Items of EEPROM Data
No. String
Default Data
14-inch 20-inch
1 DESTINATION U/C: 1 U/C: 1
AEP: 2 AEP: 2
AUS: 3 AUS: 3
2 SHARP LEVEL 4 4
3 SHARP F0 1 1
4 PRE/OVER SHOOT 0 0
5 Y DLY NTSC COMB 4 4
6 Y DLY NTSC CVBS 4 4
7 Y DLY NTSC Y/C 4 4
8 Y DLY NT443 CVBS 4 4
9 Y DLY NT443 Y/C 4 4
10 Y DLY PAL CVBS 4 4
11 Y DLY PAL Y/C 4 4
12 Y DLY SECAM CVBS 4 4
13 Y DLY SECAM Y/C 4 4
14 Y DLY PAL-M CVBS 4 4
15 Y DLY PAL-M Y/C 4 4
16 CHROMA CENT 31 31
17 PH CENT NTSC COMB 33 33
18 PH CENT NTSC CVBS 31 31
19 PH CENT NTSC Y/C 31 31
20 PH CENT NT443CVBS 33 33
21 PH CENT NT443 Y/C 35 35
22 C BPF NTSC COMB 1 1
23 C BPF NTSC CVBS 1 1
24 C BPF NTSC Y/C 0 0
25 C BPF NT443 CVBS 1 1
26 C BPF NT443 Y/C 0 0
27 C BPF PAL CVBS 1 1
28 C BPF PAL Y/C 0 0
29 C BPF SECAM CVBS 1 1
30 C BPF SECAM Y/C 0 0
31 C BPF PAL-M CVBS 1 1
32 C BPF PAL-M Y/C 0 0
33 SUB BRT CVBS 33 33
34 SUB BRT RGB 33 33
35 SECAM ID START 1 1
36 SECAM ID STOP 2 2
37
*
SECAM BELL F0 33 33
38 SECAM ID LEVEL 3 3
39 C/O R ROUGH 3 3
40 C/O G ROUGH 3 3
