Sony TRINITRON PVM-14N5MDE - Page 35

3-3
SIIA Chassis
No. String
Default Data
14-inch 20-inch
41 C/O B ROUGH 3 3
42
*
C/O OFFSET CVBS 28 49
43
*
C/O R FINE CVBS 26 21
44
*
C/O G FINE CVBS 31 31
45
*
C/O B FINE CVBS 31 29
46
*
DRV ALL CVBS No. 47, 48 and 49 are displayed.
47
*
DRV R CVBS 42 31
48
*
DRV G CVBS 36 23
49
*
DRV B CVBS 19 11
50
*
C/O OFFSET SECAM 29 50
51
*
C/O R FINE SECAM 11 11
52
*
C/O G FINE SECAM 31 31
53
*
C/O B FINE SECAM 24 23
54
*
DRV ALL SECAM No. 55, 56 and 57 are displayed.
55
*
DRV R SECAM 41 31
56
*
DRV G SECAM 36 23
57
*
DRV B SECAM 19 11
58
*
C/O OFFSET RGB 40 49
59
*
C/O R FINE RGB 30 29
60
*
C/O G FINE RGB 31 31
61
*
C/O B FINE RGB 33 32
62
*
DRV ALL RGB No. 63, 64 and 65 are displayed.
63
*
DRV R RGB 44 39
64
*
DRV G RGB 38 33
65
*
DRV B RGB 19 15
66 H OSC F0 7 7
67 H MASK 1 1
68 H SYNC SEP 0 0
69 V SYNC SEP 0 0
70 V COUNTDOWN MODE 1 1
71
*
H CENT 60HZ CVBS 11 14
72
*
H CENT 60HZ RGB 10 12
73
*
H CENT 50HZ CVBS 18 21
74
*
H CENT 50HZ RGB 13 15
75
*
H CENT NTSC COMB 12 14
76 H BLK RGB 0 0
77 H BLK CVBS 1 1
78 H BLK L 60 CVBS 15 15
79 H BLK R 60 CVBS 0 0
80 H BLK L 60 RGB 15 15
No. String
Default Data
14-inch 20-inch
81 H BLK R 60 RGB 0 0
82 H BLK L 50 CVBS 15 15
83 H BLK R 50 CVBS 0 0
84 H BLK L 50 RGB 15 15
85 H BLK R 50 RGB 0 0
86
*
BOW 7 7
87
*
ANGLE 7 7
88
*
V CENTER 32 31
89
*
V SIZE 22 23
90
*
V SIZE 16 : 9 63 63
91
*
VS-CORRECTION 3 5
92
*
V LINEARITY 7 6
93 V LIN UPPER 0 0
94 V LIN LOWER 0 0
95
*
H SIZE 21 18
96
*
H PIN PHASE 5 6
97
*
H PIN AMP 27 23
98
*
H CORNER PIN 31 34
99 EHT 8 8
100 SEC F0 TIME 0 0
101 SEC F0 DELTA 0 0
102 SEC F0 DELAY 0 0
. The data of signals marked “*” can be changed freely.
. The data of signals without “*” marked is fixed.
