Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
8-2
SIIA Chassis
[Q]
* A-1270-398-A Q BOARD, COMPLETE
****************************
(PVM-14N5A/E/U, 14N5MDE, 20N5A/E/U)
* A-1270-399-A Q BOARD, COMPLETE
****************************
(PVM-14N6A/E/U, 20N6A/E/U)
* A-1270-401-A Q BOARD, COMPLETE
****************************
(SSM-14N5A/E/U, 20N5A/E/U)
1-694-045-11 TERMINAL BOARD ASSY, I/O
(J1301, 1302, 1305, 1306, 1311-1317, 1320, 1321)
(PVM-14N6A/E/U, 20N6A/E/U)
1-694-046-11 TERMINAL BOARD ASSY, I/O
(J1301, 1302, 1305, 1306, 1317, 1320)
(PVM-14N5A/E/U, 14N5MDE, 20N5A/E/U)
1-694-047-11 TERMINAL BOARD ASSY, I/O
(J1301, 1302, 1305, 1306) (SSM-14N5A/E/U, 20N5A/E/U)
7-627-557-48 SCREW (2.6X10), +P TAPPING
<CAPACITOR>
C1303 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C1304 1-113-340-11 ELECT 47µF 20% 25V
C1305 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C1308 1-126-795-11 ELECT 10µF 20% 25V
C1317 1-126-795-11 ELECT 10µF 20% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C1319 1-126-795-11 ELECT 10µF 20% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C1320 1-126-795-11 ELECT 10µF 20% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C1322 1-126-795-11 ELECT 10µF 20% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C1325 1-126-795-11 ELECT 10µF 20% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C1326 1-126-795-11 ELECT 10µF 20% 25V
C1327 1-126-795-11 ELECT 10µF 20% 25V
C1328 1-126-795-11 ELECT 10µF 20% 25V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1329 1-126-795-11 ELECT 10µF 20% 25V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1330 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1331 1-126-795-11 ELECT 10µF 20% 25V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1332 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C1333 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1334 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
(PVM-14N6A/E/U, 20N6A/E/U)
C1335 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C1341 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1342 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1343 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1344 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1345 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1346 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1347 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C1348 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1349 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1350 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1350 1-216-295-91 SHORT 0
(SSM-14N5A/E/U, 20N5A/E/U)
C1351 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1351 1-216-295-91 SHORT 0
(SSM-14N5A/E/U, 20N5A/E/U)
C1352 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1352 1-216-295-91 SHORT 0
(SSM-14N5A/E/U, 20N5A/E/U)
C1353 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
C1353 1-216-295-91 SHORT 0
(SSM-14N5A/E/U, 20N5A/E/U)
C1354 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1355 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1356 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1357 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1358 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1359 1-113-340-11 ELECT 47µF 20% 25V
C1360 1-113-340-11 ELECT 47µF 20% 25V
C1361 1-113-340-11 ELECT 47µF 20% 25V
C1362 1-113-340-11 ELECT 47µF 20% 25V
<CONNECTOR>
CN1301 * 1-564-521-11 PLUG, CONNECTOR 6P
CN1302 * 1-564-522-11 PLUG, CONNECTOR 7P
(except SSM-14N5A/E/U, 20N5A/E/U)
CN1303 * 1-564-522-11 PLUG, CONNECTOR 7P
(except PVM-14N5A/E/U, 14N5MDE, 20N5A/E/U)
<DIODE>
D1300 8-719-991-33 DIODE 1SS133T-77
D1301 8-719-991-33 DIODE 1SS133T-77
D1302 8-719-991-33 DIODE 1SS133T-77
D1303 8-719-991-33 DIODE 1SS133T-77
D1304 8-719-991-33 DIODE 1SS133T-77
D1305 8-719-991-33 DIODE 1SS133T-77
D1308 8-719-991-33 DIODE 1SS133T-77
D1309 8-719-991-33 DIODE 1SS133T-77
D1314 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1315 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1316 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1317 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1318 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1319 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1320 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1321 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1322 8-719-923-74 DIODE MTZJ-T-77-11A
(PVM-14N6A/E/U, 20N6A/E/U)
