Sony TRINITRON PVM-14N5MDE - Page 55

Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
8-3
SIIA Chassis
[Q]
D1324 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1325 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1326 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1327 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1328 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1329 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1330 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1331 8-719-991-33 DIODE 1SS133T-77
(except SSM-14N5A/E/U, 20N5A/E/U)
D1332 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
D1333 8-719-991-33 DIODE 1SS133T-77
(PVM-14N6A/E/U, 20N6A/E/U)
<IC>
IC1301 8-759-984-96 IC BA7604N
<JACK>
J1303 1-565-167-12 TERMINAL, (S) (WITH SW) 4P
J1304 1-569-578-11 TERMINAL, S (WITH SW)
J1319 1-565-167-12 TERMINAL, (S) (WITH SW) 4P
(except SSM-14N5A/E/U, 20N5A/E/U)
<TRANSISTOR>
Q1302 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1305 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1308 8-729-119-78 TRANSISTOR 2SC2785-HFE
(PVM-14N6A/E/U, 20N6A/E/U)
Q1309 8-729-119-78 TRANSISTOR 2SC2785-HFE
(PVM-14N6A/E/U, 20N6A/E/U)
Q1310 8-729-119-78 TRANSISTOR 2SC2785-HFE
(PVM-14N6A/E/U, 20N6A/E/U)
Q1311 8-729-119-76 TRANSISTOR 2SA1175-HFE
(PVM-14N6A/E/U, 20N6A/E/U)
Q1312 8-729-119-78 TRANSISTOR 2SC2785-HFE
(PVM-14N6A/E/U, 20N6A/E/U)
Q1313 8-729-119-78 TRANSISTOR 2SC2785-HFE
(except SSM-14N5A/E/U, 20N5A/E/U)
Q1314 8-729-119-76 TRANSISTOR 2SA1175-HFE
(except SSM-14N5A/E/U, 20N5A/E/U)
<RESISTOR>
R1303 1-216-009-00 RES,CHIP 22 5% 1/10W
R1304 1-214-702-00 METAL 75 1% 1/4W
R1305 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1307 1-214-702-00 METAL 75 1% 1/4W
R1308 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1309 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1310 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1311 1-214-702-00 METAL 75 1% 1/4W
R1312 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1317 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1318 1-216-119-00 RES,CHIP 820K 5% 1/10W
R1319 1-216-107-00 RES,CHIP 270K 5% 1/10W
R1320 1-216-097-00 RES,CHIP 100K 5% 1/10W
R1321 1-216-095-00 RES,CHIP 82K 5% 1/10W
R1331 1-216-049-91 RES,CHIP 1K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1332 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1333 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1335 1-216-049-91 RES,CHIP 1K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1336 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1337 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1338 1-216-009-00 RES,CHIP 22 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1339 1-214-702-00 METAL 75 1% 1/4W
(PVM-14N6A/E/U, 20N6A/E/U)
R1340 1-216-049-91 RES,CHIP 1K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1341 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1342 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1343 1-216-009-00 RES,CHIP 22 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1344 1-214-702-00 METAL 75 1% 1/4W
(PVM-14N6A/E/U, 20N6A/E/U)
R1345 1-216-009-00 RES,CHIP 22 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1346 1-214-702-00 METAL 75 1% 1/4W
(PVM-14N6A/E/U, 20N6A/E/U)
R1347 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1348 1-216-119-00 RES,CHIP 820K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1349 1-216-107-00 RES,CHIP 270K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1350 1-216-097-00 RES,CHIP 100K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1351 1-216-095-00 RES,CHIP 82K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1352 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1355 1-216-049-91 RES,CHIP 1K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1356 1-214-702-00 METAL 75 1% 1/4W
(PVM-14N6A/E/U, 20N6A/E/U)
R1358 1-247-791-91 CARBON 22 5% 1/4W
R1360 1-214-702-00 METAL 75 1% 1/4W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1361 1-247-791-91 CARBON 22 5% 1/4W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1362 1-216-009-00 RES,CHIP 22 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1363 1-214-702-00 METAL 75 1% 1/4W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1364 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
