Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
8-4
SIIA Chassis
[Q][A]
R1365 1-214-702-00 METAL 75 1% 1/4W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1366 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1367 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
(except SSM-14N5A/E/U, 20N5A/E/U)
R1368 1-216-073-00 RES,CHIP 10K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1369 1-216-073-00 RES,CHIP 10K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1370 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1371 1-216-095-00 RES,CHIP 82K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1372 1-216-097-00 RES,CHIP 100K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1373 1-216-119-00 RES,CHIP 820K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1374 1-216-107-00 RES,CHIP 270K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1375 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
(except SSM-14N5A/E/U, 20N5A/E/U)
R1376 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1378 1-216-009-00 RES,CHIP 22 5% 1/10W
(PVM-14N6A/E/U, 20N6A/E/U)
R1380 1-216-047-91 RES, CHIP 820 5% 1/10W
R1381 1-216-047-91 RES, CHIP 820 5% 1/10W
**********************************************************************************
* A-1298-614-A A BOARD, COMPLETE
****************************
(PVM-14N5A/E/U)
* A-1298-615-A A BOARD, COMPLETE
***************************
(PVM-14N6A/E/U)
* A-1298-619-A A BOARD, COMPLETE
***************************
(PVM-20N5A/E/U)
* A-1298-621-A A BOARD, COMPLETE
***************************
(PVM-20N6A/E/U)
* A-1298-622-A A BOARD, COMPLETE
***************************
(SSM-20N5A/E/U)
* A-1298-623-A A BOARD, COMPLETE
***************************
(SSM-14N5A/E/U)
* A-1298-624-A A BOARD, COMPLETE
***************************
(PVM-14N5MDE)
1-533-223-11 HOLDER, FUSE
1-540-044-11 SOCKET, IC
4-200-407-01 HOLDER, LED
4-201-023-01 SPACER, INSULATING
4-202-373-01 SPRING, IC
4-382-854-11 SCREW (M3X10), P, SW (+)
<CAPACITOR>
C001 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C002 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C003 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C006 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
(PVM-14N6A/E/U, 20N6A/E/U)
C007 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C008 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C010 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C011 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C012 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C013 1-126-964-11 ELECT 10µF 20% 50V
C014 1-163-253-11 CERAMIC CHIP 120PF 5% 50V
C015 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C016 1-126-933-11 ELECT 100µF 20% 16V
C017 1-126-964-11 ELECT 10µF 20% 50V
C018 1-126-964-11 ELECT 10µF 20% 50V
C019 1-126-964-11 ELECT 10µF 20% 50V
C020 1-126-964-11 ELECT 10µF 20% 50V
C021 1-126-964-11 ELECT 10µF 20% 50V
C022 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C023 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C024 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C025 1-136-165-00 FILM 0.1µF 5% 50V
C026 1-104-664-11 ELECT 47µF 20% 16V
C027 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C028 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C030 1-104-664-11 ELECT 47µF 20% 16V
C031 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C032 1-104-664-11 ELECT 47µF 20% 16V
C101 1-107-907-11 ELECT 22µF 20% 50V
C102 1-107-635-11 ELECT 4.7µF 20% 160V
C103 1-102-050-00 CERAMIC 0.01µF 500V
C201 1-126-964-11 ELECT 10µF 20% 50V
C202 1-126-964-11 ELECT 10µF 20% 50V
C203 1-126-934-11 ELECT 220µF 20% 16V
C204 1-126-964-11 ELECT 10µF 20% 50V
C206 1-126-940-11 ELECT 330µF 20% 25V
C207 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C208 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C301 1-126-960-11 ELECT 1µF 20% 50V
C302 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C303 1-107-714-11 ELECT 10µF 20% 50V
C304 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C305 1-126-964-11 ELECT 10µF 20% 50V
C306 1-126-964-11 ELECT 10µF 20% 50V
C307 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C308 1-126-961-11 ELECT 2.2µF 20% 50V
C309 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C310 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C311 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
C312 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
(PVM-14N6A/E/U, 20N6A/E/U)
