Sony TRINITRON PVM-14N5MDE - Page 63

Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
8-11
SIIA Chassis
[A][CA]
R1415 1-216-025-91 RES,CHIP 100 5% 1/10W
R1416 1-216-025-91 RES,CHIP 100 5% 1/10W
R1417 1-216-025-91 RES,CHIP 100 5% 1/10W
R1418 1-216-025-91 RES,CHIP 100 5% 1/10W
R1419 1-216-025-91 RES,CHIP 100 5% 1/10W
R1420 1-216-025-91 RES,CHIP 100 5% 1/10W
R1421 1-216-025-91 RES,CHIP 100 5% 1/10W
<SWITCH>
S001 1-571-532-21 SWITCH, TACTIL
S002 1-571-532-21 SWITCH, TACTIL
S003 1-571-532-21 SWITCH, TACTIL
S004 1-571-532-21 SWITCH, TACTIL
S006 1-571-532-21 SWITCH, TACTIL
(PVM-14N6A/E/U, 20N6A/E/U)
S007 1-571-532-21 SWITCH, TACTIL
(except SSM-14N5A/E/U, 20N5A/E/U)
S008 1-571-532-21 SWITCH, TACTIL
(except SSM-14N5A/E/U, 20N5A/E/U)
S501 1-554-186-00 SWITCH, LEVER
S601 ! 1-571-433-31 SWITCH, PUSH (AC POWER)
<SPARK GAP>
SG501 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 ! 1-453-277-11 TRANSFORMER ASSY, FLYBACK
(NX-4008//U2A4) (20inch model)
T501 ! 1-453-278-11 TRANSFORMER ASSY, FLYBACK
(NX-4301//U2A4) (14inch model)
T502 1-437-090-31 HDT
T601 1-429-265-11 TRANSFORMER, CONVERTER (SRT)
T603 ! 1-429-482-11 TRANSFORMER, LINE FILTER
<THERMISTOR>
THP601!1-808-059-32 THERMISTOR, POSITIVE
<CRYSTAL>
X001 1-567-781-11 VIBRATOR, CRYSTAL
X301 1-567-504-11 OSCILLATOR, CRYSTAL
X302 1-567-505-11 OSCILLATOR, CRYSTAL
*********************************************************************************
* A-1331-827-A CA BOARD, COMPLETE
*****************************
(14inch model)
* 4-374-912-01 COVER (MAIN), CV VOL
* 4-374-913-01 COVER (REAR LID), CV VOL
<CAPACITOR>
C709 1-136-601-11 FILM 0.01µF 10% 630V
C710 1-102-002-00 CERAMIC 680PF 10% 500V
C711 1-102-002-00 CERAMIC 680PF 10% 500V
C712 1-102-002-00 CERAMIC 680PF 10% 500V
C716 1-126-940-11 ELECT 330µF 20% 25V
C721 1-107-667-11 ELECT 2.2µF 20% 400V
C723 1-162-116-00 CERAMIC 680PF 10% 2KV
C724 ! 1-102-959-91 CERAMIC 22PF 5% 50V
<CONNECTOR>
CN701 *1-508-768-00 PIN, CONNECTOR (5mm PITCH) 6P
CN702 *1-564-509-11 PLUG, CONNECTOR 6P
CN703 1-695-915-11 TAB (CONTACT)
<DIODE>
D710 8-719-991-33 DIODE 1SS133T-77
D711 8-719-991-33 DIODE 1SS133T-77
D712 8-719-991-33 DIODE 1SS133T-77
D713 8-719-991-33 DIODE 1SS133T-77
D714 8-719-991-33 DIODE 1SS133T-77
D715 8-719-991-33 DIODE 1SS133T-77
D716 8-719-991-33 DIODE 1SS133T-77
<JACK>
J701 ! 1-526-819-11 SOCKET, PICTURE TUBE
<COIL>
L701 1-410-671-31 INDUCTOR 47µH
<TRANSISTOR>
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q710 8-729-200-17 TRANSISTOR 2SA1091-O
Q711 8-729-200-17 TRANSISTOR 2SA1091-O
Q712 8-729-200-17 TRANSISTOR 2SA1091-O
Q713 8-729-906-70 TRANSISTOR BF871-127
Q714 8-729-906-70 TRANSISTOR BF871-127
Q715 8-729-906-70 TRANSISTOR BF871-127
<RESISTOR>
R701 1-202-846-00 SOLID 470K 20% 1/2W
R702 1-202-846-00 SOLID 470K 20% 1/2W
R703 1-202-719-00 SOLID 1M 20% 1/2W
R704 1-202-838-00 SOLID 100K 20% 1/2W
R705 1-202-842-11 SOLID 220K 20% 1/2W
R706 1-202-818-00 SOLID 1K 20% 1/2W
R707 1-202-818-00 SOLID 1K 20% 1/2W
R708 1-202-818-00 SOLID 1K 20% 1/2W
R715 1-247-807-31 CARBON 100 5% 1/4W
R716 1-247-807-31 CARBON 100 5% 1/4W
R717 1-247-807-31 CARBON 100 5% 1/4W
R722 1-216-372-11 METAL OXIDE 1.8 5% 2W F
R723 1-216-487-11 METAL OXIDE 12K 5% 3W F
R724 1-216-487-11 METAL OXIDE 12K 5% 3W F
R725 1-216-487-11 METAL OXIDE 12K 5% 3W F
