Sony TRINITRON PVM-14N5MDE - Page 64

Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
8-12
SIIA Chassis
[CA][CB]
R730 1-249-409-11 CARBON 220 5% 1/4W F
R731 1-247-903-00 CARBON 1M 5% 1/4W
R732 ! 1-202-549-81 SOLID 100 20% 1/2W
R751 1-249-412-11 CARBON 390 5% 1/4W
R752 1-249-412-11 CARBON 390 5% 1/4W
R753 1-249-412-11 CARBON 390 5% 1/4W
<VARIABLE RESISTOR>
RV701 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
RV702 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
RV703 1-230-798-11 RES, ADJ, METAL GLAZE 90M
**********************************************************************************
* A-1331-828-A CB BOARD, COMPLETE
*****************************
(20inch model)
<CAPACITOR>
C709 1-136-601-11 FILM 0.01µF 10% 630V
C710 1-102-002-00 CERAMIC 680PF 10% 500V
C711 1-102-002-00 CERAMIC 680PF 10% 500V
C712 1-102-002-00 CERAMIC 680PF 10% 500V
C716 1-126-940-11 ELECT 330µF 20% 25V
C721 1-107-667-11 ELECT 2.2µF 20% 400V
C723 1-162-116-00 CERAMIC 680PF 10% 2KV
C724 ! 1-102-959-91 CERAMIC 22PF 5% 50V
<CONNECTOR>
CN701 *1-508-768-00 PIN, CONNECTOR (5mm PITCH) 6P
CN702 *1-564-509-11 PLUG, CONNECTOR 6P
CN703 1-695-915-11 TAB (CONTACT)
<DIODE>
D710 8-719-991-33 DIODE 1SS133T-77
D711 8-719-991-33 DIODE 1SS133T-77
D712 8-719-991-33 DIODE 1SS133T-77
D713 8-719-991-33 DIODE 1SS133T-77
D714 8-719-991-33 DIODE 1SS133T-77
D715 8-719-991-33 DIODE 1SS133T-77
D716 8-719-991-33 DIODE 1SS133T-77
<JACK>
J702 ! 1-540-124-21 SOCKET, PICTURE TUBE
<COIL>
L701 1-410-478-11 INDUCTOR 47µH
<TRANSISTOR>
Q710 8-729-200-17 TRANSISTOR 2SA1091-O
Q711 8-729-200-17 TRANSISTOR 2SA1091-O
Q712 8-729-200-17 TRANSISTOR 2SA1091-O
Q713 8-729-906-70 TRANSISTOR BF871-127
Q714 8-729-906-70 TRANSISTOR BF871-127
Q715 8-729-906-70 TRANSISTOR BF871-127
Q731 8-729-119-76 TRANSISTOR 2SA1175-HFE
<RESISTOR>
R701 1-202-846-00 SOLID 470K 20% 1/2W
R702 1-202-838-00 SOLID 100K 20% 1/2W
R703 1-202-838-00 SOLID 100K 20% 1/2W
R705 1-202-842-11 SOLID 220K 20% 1/2W
R706 1-202-818-00 SOLID 1K 20% 1/2W
R707 1-202-818-00 SOLID 1K 20% 1/2W
R708 1-202-818-00 SOLID 1K 20% 1/2W
R715 1-247-807-31 CARBON 100 5% 1/4W
R716 1-247-807-31 CARBON 100 5% 1/4W
R717 1-247-807-31 CARBON 100 5% 1/4W
R722 1-216-412-11 METAL OXIDE 1.8 5% 5W F
R723 1-215-923-00 METAL OXIDE 10K 5% 3W F
R724 1-216-487-11 METAL OXIDE 12K 5% 3W F
R725 1-216-487-11 METAL OXIDE 12K 5% 3W F
R730 1-249-409-11 CARBON 220 5% 1/4W F
R731 1-247-903-00 CARBON 1M 5% 1/4W
R732 ! 1-202-549-81 SOLID 100 20% 1/2W
R751 1-249-412-11 CARBON 390 5% 1/4W
R752 1-249-412-11 CARBON 390 5% 1/4W
R753 1-249-412-11 CARBON 390 5% 1/4W
<VARIABLE RESISTOR>
RV701 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
RV703 1-241-714-11 RES, ADJ, METAL FILM 110M
**********************************************************************************
MISCELLANEOUS
**********************
! 1-251-263-11 INLET, AC
! 1-411-750-11 COIL, DEMAGNETIC (20inch model)
! 1-426-442-21 COIL, DEMAGNETIC (14inch model)
! 1-451-349-12 DEFLECTION YOKE (Y20FZA)
(20inch model)
1-452-032-00 MAGNET, DISC
1-505-188-11 SPEAKER (4X7CM)
1-543-653-11 CORE ASSY, BEAD(DIVISION TYPE)
* 1-900-214-07 WIRE ASSY, SEFETY EARTH
! 8-451-472-11 DEFLECTION YOKE (Y14MGAT)
(14inch model)
V901 ! 8-736-135-05 PICTURE TUBE (M49KGH10X)
(20inch model)
V901 ! 8-738-342-05 PICTURE TUBE (M34KBE10X)
(14inch model)
*********************************************************************************
