16 (US)
Display List
USER CONFIG 1/2, 2/2 menu
·RGB/COMP SEL COMP
·1125/60I SYS 1080
·MATRIX 601
·COMP LEVEL SMPTE
·NTSC SETUP 0
·FORMAT DISP AUTO
·LANGUAGE ENGL I SH
USER CONF IG 1 / 2
x CAPT I ON OFF
·DEGAUSS DELAY 0
·MARKER PHASE 0
·MARKER WI DTH 0
USER CONF IG 2 / 2
REMOTE 1/2 PARALLEL menu, 2/2 SERIAL menu
·1PIN LINE A
·2PIN LINE B
·3PIN TALLY R
·4PIN TALLY G
·6PIN EXT SYNC
·7PIN UNDERSCAN
·8PIN 16:9
REMOTE 1 / 2 PARAL LEL
x SINGLE ADDRESS 0
·GROUP ADDRESS 0
·CH(1–4) CONFIG CH1
·INPUT LINE A
·ASPECT 4:3
·SCAN SIZE NORMAL
REMOTE 2 / 2 SER I AL
OPTION CONFIG menu
For details on the OPTION CONFIG menu screens, see page 21 (US).
KEY PROTECT menu
·KEY PROTECT OFF
KEY PROTECT
(USER CONFIG 1/2 menu) (USER CONFIG 2/2 menu)
(REMOTE 1/2 PARALLEL menu) (REMOTE 2/2 SERIAL menu)
To Next Page
