23 (US)
Specifications
General
System
Frame
System
Total lines Active lines
rate
Scanning Aspect
Standard
per frame per frame
(Hz)
format ratio
575/50I (PAL) 625 575 25 2:1 Interlace 16:9/4:3 ITU 601
480/60I (NTSC) 525 483 30 2:1 Interlace 16:9/4:3 ITU 601
576/50P 625 576 50 Progressive 16:9/4:3 —
480/60P 525 483 60 Progressive 16:9/4:3 SMPTE 293M
1080/48I 1125 1080 24 2:1 Interlace 16:9 —
1080/50I 1125 1080 25 2:1 Interlace 16:9 SMPTE 294M
1035/60I 1125 1035 30 2:1 Interlace 16:9 BTA S-001B
1080/60I 1125 1080 30 2:1 Interlace 16:9 SMPTE 274M/BTA S-001B
720/60P 750 720 60 Progressive 16:9 SMPTE 296M
PVM-14L5
CRT: HR Trinitron, SMPTE-C standard
luminescent material
Power: AC100 to 240V, 50/60Hz
Power consumption:
Maximum 120W, 1.2 to 0.6A
(when the optional BKM-150CP
has been installed)
Standard: 110W, 1.1 to 0.5A
(Without optional board, 720/60P
input)
Dimensions (max.):
Approx. 346 × 280 × 424mm
(13
5
/8 × 11
1
/8 × 16
3
/4 inches)
(w/h/d)
Mass: Approx. 17kg (37 lb 8 oz)
PVM-20L5
CRT: HR Trinitron, SMPTE-C standard
luminescent material
Power: AC100 to 240V, 50/60Hz
Power consumption:
Maximum 140W, 1.4 to 0.7A
(when the optional BKM-150CP
has been installed)
Standard: 130W, 1.3 to 0.6A
(Without optional board, 720/60P
input)
Dimensions (max.):
Approx. 452 × 414 × 500mm
(17
7
/8 × 16
3
/8 × 19
3
/4 inches)
(w/h/d)
Mass: Approx. 31kg (68 lb 5 oz)
Input/output connectors
Input
LINE A input connector
Y/C input 4-pin mini-DIN (1)
See the pin assignment
VIDEO input
BNC type (1) 1Vp-p ± 6dB
negative synchronization
AUDIO input
Pin jack (1) –5dBu 47 kΩ or higher
LINE B input connector
VIDEO input
BNC type (1) 1Vp-p ± 6dB
negative synchronization
AUDIO input
Pin jack (1) –5dBu 47 kΩ or higher
RGB/Component input connector
BNC type (3)
RGB input 0.7Vp-p ± 6dB (Sync On Green,
0.3Vp-p negative sync.)
Component input
0.7Vp-p ± 6dB (75% chrominance
standard color bar signal)
AUDIO input
Pin jack (1) –5dBu 47 kΩ or higher
Externally synchronized input
BNC type (1) 0.3 to 8Vp-p
± bipolarity ternary or negative
polarity binary
