Specifications
42
Hand-held microphone
(UTX-H1)
Microphone unit
Dynamic
Directivity
Unidirectional
Antenna 1/4λ (wave length) wire
(internal)
Dimensions
φ 52 × 240 mm (2
1
/8 × 9
1
/2
inches) (dia/length)
Mass Approx. 300 g (11 oz)
including batteries
Tuners (URX-P1/R1/M1)
Items common to all tuners
Type of reception
Space diversity
Oscillator type
Crystal-controlled PLL
synthesizer
Reception frequencies
794 to 806 MHz
Operating frequency band
12 MHz
Signal-to-noise ratio
60 dB or more
De-emphasis
50 µs
Reference deviation
±5 kHz
Frequency characteristics
50 Hz to 18 kHz
Distortion
1.0% or less at 1 kHz
modulation
Tone signal
32 kHz
Indicator RF input level
Portable diversity tuner
(URX-P1)
Antenna 1/4λ (wave length) wire
(adjustable angle)
Squelch level
15 dBµ
Audio output level
–58 dBm
Audio output connector
3.5 mm dia. mini jack
Headphones output level
5 mW (16Ω)
