43
Display Channel, frequency, audio
level, RF level,
accumulated battery use
time, monitor level
Power requirements
3.0 V DC (two LR6/AA-
size alkaline batteries)
Battery life
Approx. 6 hours
Dimensions
63 × 100 × 30 mm (2
1
/2 × 4
× 1
3
/16 inches) (w/h/d)
(excluding the antennas)
Mass Approx. 180 g (6 oz)
including batteries
Half-rack size diversity tuner
(URX-R1)
Antenna 1/4λ (wave length) wire
(adjustable angle)
Squelch level
25 dBµ
Balanced audio output level
–28 dBm (LINE level)/–58
dBm (MIC level)
selectable
Unbalanced audio output level
–30 dBm
Audio output connectors
XLR-3-32 type, balanced
1/4-inch jack, unbalanced
(LINE level only)
Headphones output level
5 mW (16Ω)
Display Channel, frequency
Power requirements
9.0 V DC
Dimensions
212 × 44 × 209 mm (8
3
/8 ×
1
3
/4 × 8
1
/4 inches) (w/h/d)
(excluding the antennas)
