DIP Switch
DIP switch setting is different by the type of LCD. For setting method, please refer to the table.
3-12
(END)
[Sony Confidential]
VGN-AW Series (9-852-817-XX)
VGN- AW210J/AW290/AW290C (AM)
VGN- AW21M (EU)
18.4 TFT(Samsung) (A-1609-704-A/A-1709-517-A)
VGN-AW51JGB/AW81DS/AW81JS/AW81YS/AW91CDS/AW91CJS/AW91CYS/AW91DS/AW91JS/AW91YS (J)
VGN- AW220J/AW230J/AW235J/AW290/AW290C (AM)
VGN-AW21S/AW21SR/AW21Z/AW21ZR (EU)
VGN-AW25GJ (AO)
18.4 TFT(Samsung) (A-1609-705-A)
VGN-AW71JB/AW81DS/AW81JS/AW81YS/AW91CDS/AW91CJS/AW91CYS/AW91DS/AW91JS/AW91YS (J)
VGN-AW270Y/AW280TY/AW270E/AW290/AW290C (AM)
VGN-AW21XY/AW 2XRY/AW21VY (EU)
VGN-AW27GY(AO)
18.4 TFT(Samsung) (A-1609-706-B/A-1609-706-A)
