Sony VGN-TXN15BP - Table of Contents

- 3 -
VGN-TXN15BP/TXN15P/TXN17P/TXN17P7/TXN19P (AM)
VGN-TX45LP/TX46C/TX46GP/TX46SP/TX46TP/TX47CP/TX47GP/TX47LP/TX47SP/TX47TP/TX48CP (AO)
Sony Confidential
TABLE OF CONTENTS
Section Title Page
CHAPTER 1. SPECIFICATIONS
1-1. Specifications ...................................................................................................................................... 1-1
(to 1-2)
CHAPTER 2. BLOCK DIAGRAM .............................................................................................. 2-1
(to 2-1)
CHAPTER 3. FRAME HARNESS DIAGRAM ................................................................. 3-1
(to 3-1)
CHAPTER 4. EXPLODED VIEWS AND PARTS LIST
Note ............................................................................................................................................................ 4-2
Palmrest
P-1 .......................................................................................................................................................... 4-3
Main Board
M-1 ........................................................................................................................................................ 4-5
Bottom
B-1 (WAN Model) ................................................................................................................................. 4-7
B-2 (No-WAN Model) .......................................................................................................................... 4-9
LCD
L-1. 11.1/WXGA HDAR/BR (To) ...................................................................................................... 4-11
Accessories
A-1 ....................................................................................................................................................... 4-13
(to 4-13)
History of the changes is shown as the
“Revision History” at the end of this data.
ᄌᦝጁᱧߪޔ“ Revision History ” ߣߒߡޔ
ᧄ࠺࡯࠲ᧃߦ⸥タߒߡ޽ࠅ߹ߔޕ
Section Title Page
CHAPTER 5. OTHERS
5-1. Precautions for Handling the Drive ................................................................................................... 5-1
5-2. Note for WAN Board Replacement .................................................................................................... 5-2
(to 5-2)
