Sony VGN-TXN15BP - Palmrest; Main Board M-1; Bottom

CHAPTER 4.
EXPLODED VIEWS AND PARTS LIST
4 - 1
VGN-TXN15BP/TXN15P/TXN17P/TXN17P7/TXN19P (AM)
VGN-TX45LP/TX46C/TX46GP/TX46SP/TX46TP/TX47CP/TX47GP/TX47LP/TX47SP/TX47TP/TX48CP (AO)
Sony Confidential
Palmrest Main Board Bottom LCD Accessories
TXN19P/L P-1 M-1 B-1 L-1 A-1
TXN17P/B P-1 M-1 B-1 L-1 A-1
TXN17P/T P-1 M-1 B-1 L-1 A-1
TXN15P/B P-1 M-1 B-1 L-1 A-1
AM
TXN15P/T P-1 M-1 B-1 L-1 A-1
TXN15P/W P-1 M-1 B-1 L-1 A-1
TXN17P7 P-1 M-1 B-1 L-1 A-1
TXN15BP P-1 M-1 B-2 L-1 A-1
TX48CP/L P-1 M-1 B-2 L-1 A-1
TX47CP/B P-1 M-1 B-2 L-1 A-1
TX47CP/L P-1 M-1 B-2 L-1 A-1
TX46C/B P-1 M-1 B-2 L-1 A-1
TX46C/T P-1 M-1 B-2 L-1 A-1
TX46C/W P-1 M-1 B-2 L-1 A-1
TX47GP/B P-1 M-1 B-2 L-1 A-1
AO
TX47GP/T P-1 M-1 B-2 L-1 A-1
TX47GP/W P-1 M-1 B-2 L-1 A-1
TX47LP/B P-1 M-1 B-2 L-1 A-1
TX47TP/B P-1 M-1 B-2 L-1 A-1
TX47SP/B P-1 M-1 B-2 L-1 A-1
TX46GP/W P-1 M-1 B-2 L-1 A-1
TX46TP/W P-1 M-1 B-2 L-1 A-1
TX46SP/W P-1 M-1 B-2 L-1 A-1
TX45LP/W P-1 M-1 B-2 L-1 A-1
Section Page
Note ................................................................................... 4-2
Palmrest
P-1 ............................................................................. 4-3
Main Board
M-1 ........................................................................... 4-5
Bottom
B-1 (WAN Model) .................................................... 4-7
B-2 (No-WAN Model) ............................................. 4-9
LCD
L-1. 11.1/WXGA HDAR/BR (To) ......................... 4-11
Accessories
A-1 .......................................................................... 4-13
• ಽ⸃࿑䈫ㇱຠ⴫䈲㪅㩷䊌䊷䊛䊧䉴䊃㪃㩷䊗䊃䊛䈭䈬䈱䊑䊨䉾䉪䈗䈫䈮ಽ䈎䉏䈩䈇䉁䈜䇯
ᯏ⒳䈮䉋䈦䈩ㇱຠ⴫䈱䉶䉪䉲䊢䊮䈏⇣䈭䉍䉁䈜䈱䈪㪃㩷⹦⚦䈲ฝ䈱৻ⷩ⴫䉕ෳᾖ䈚䈩䈒䈣䈘䈇䇯
• The parts list is compiled by blocks of a palmrest andbottom etc.
The sections of the parts list are different depending on the model.
Please refer to list of contents shown in the below.
Palmrest
LCD
Bottom
Main Board
