Specifications
RS-232C connector (D-Sub 9-pin,
male)
USB connector (Type A, female)
USB connector (Type B, female)
1NC 6NC
2RXDA 7RTS
3TXDA 8CTS
4DTR 9NC
5GND
1V
BUS
(4.4 - 5.25 V)
2 Data–
3 Data+
4Ground
1VCC (+5 V)
2 Data–
3 Data+
4Ground
51
9
6
