Pin No. Pin Name I/O Description
34 MOTOR DIR O
Motor direction control signal output to the capstan/reel motor drive (IC601)
“L”: counterclockwise, “H”: clockwise
35 SPEED CTL O
Motor speed control signal output to the capstan/reel motor drive (IC601)
“L”: normal speed, “H”: 1/2 speed
36 MUTE O Power on mute control signal output to the TA2123FA (IC301) “L”: mute on
37 VSS1 — Ground terminal
38 PM CTL O Plunger drive signal output terminal “L”: plunger on
39 LED AVLS O LED drive signal output of the AVLS indicator (D705) “L”: LED on
40 LED BL SKIP O
LED drive signal output of the BL SKIP/s indicator (D706) “L”: LED on
41, 42 NC — Not used (open)
43 AVDD — Power supply terminal (+2.5V) (for A/D converter)
44 AVREF I Reference voltage input terminal (+2.5V) (for A/D converter)
