Sony Walkman WM-EX500 Service Manual

– 28 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
WM-EX500/EX505
R717 1-216-849-11 METAL CHIP 220K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R719 1-216-809-11 METAL CHIP 100 5% 1/16W
(EX505)
R720 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R721 1-218-839-11 METAL CHIP 470 0.5% 1/16W
R722 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R723 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R724 1-218-859-11 METAL CHIP 3.3K 0.5% 1/16W
R725 1-218-859-11 METAL CHIP 3.3K 0.5% 1/16W
R726 1-216-821-11 METAL CHIP 1K 5% 1/16W
R727 1-216-821-11 METAL CHIP 1K 5% 1/16W
R728 1-216-821-11 METAL CHIP 1K 5% 1/16W
R731 1-216-857-11 METAL CHIP 1M 5% 1/16W
R732 1-216-849-11 METAL CHIP 220K 5% 1/16W
R733 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R734 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R735 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R736 1-218-867-11 METAL CHIP 6.8K 0.5% 1/16W
R737 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R738 1-218-859-11 METAL CHIP 3.3K 0.5% 1/16W
R739 1-216-847-11 METAL CHIP 150K 5% 1/16W
R740 1-216-847-11 METAL CHIP 150K 5% 1/16W
R750 1-216-845-11 METAL CHIP 100K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-227-167-21 RES, VAR, CARBON 30K/30K (VOL)
RV601 1-223-576-11 RES, ADJ, METAL GLAZE 2.2K
< SWITCH >
S701 1-771-475-21 SWITCH, SLIDE (DIRECTION)
S702 1-771-851-21 SWITCH, TACTILE (SMD) (x)
S703 1-771-851-21 SWITCH, TACTILE (SMD) (Y REPEAT)
S704 1-771-851-21 SWITCH, TACTILE (SMD) (FF AMS)
S705 1-771-851-21 SWITCH, TACTILE (SMD) (REW AMS)
S706 1-771-851-21 SWITCH, TACTILE (SMD) (SOUND)
S707 1-572-922-11 SWITCH, SLIDE (HOLD)
S708 1-771-851-21 SWITCH, TACTILE (SMD) (FUNCTION)
< THERMISTOR (POSITIVE) >
THP601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X701 1-767-289-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
MISCELLANEOUS
**************
HP901 1-500-576-12 HEAD, MAGNETIC (PLAYBACK)
M901 1-763-166-14 MOTOR (CAPSTAN/REEL) (WITH PULLEY)
PM901 1-454-674-41 SOLENOID, PLUNGER
S901 1-771-888-11 SWITCH, LEAF (TAPE DETECT)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-868-001-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH, PORTUGUESE,
ITALIAN) (EX505: AEP, FRENCH)
3-868-001-21 MANUAL, INSTRUCTION
(GERMAN, DUTCH, SWEDISH, FINNISH)
(EX505: AEP)
3-868-001-31 MANUAL, INSTRUCTION
(ENGLISH, CHINESE) (EX505: 9E)
3-868-002-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH, PORTUGUESE,
GERMAN, ITALIAN, DUTCH, SWEDISH,
FINNISH) (EX500: EXCEPT EE)
3-868-002-21 MANUAL, INSTRUCTION
(ENGLISH, HUNGARIAN, POLISH, RUSSIAN,
CZECH, SLOVAKIAN) (EX500: EE)
8-953-130-90 HEADPHONE MDR-E805LP (EX500)
8-953-304-90 RECEIVER MDR-E805SP (EX505)
A-3052-138-A REMOTE CONTROL ASSY (RM-WME5)
(EX505)
Sony Corporation
Personal Audio Division Company
9-927-634-11
2000A0567-1
Printed in Japan C 2000. 1
Published by General Engineering Dept.
