– 7 –
CASE ASSY
ORNAMENT ASSY
1 three screws
(M1.4 × 3.0)
1 two screws
(M1.4 × 3.0)
2 case assy
1 two claws
2 ornament assy
1 claw
knob (hold)
S707
On installation reel ornament,
adjust the S707 and knob (hold).
