Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
9
WM-D6C/TC-D6C
MAIN
C237 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C238 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C239 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C241 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C242 1-135-070-00 TANTALUM CHIP 0.1uF 10% 35V
C243 1-104-915-11 TANTALUM CHIP 2.2uF 20% 16V
C244 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
C245 1-104-551-11 FILM CHIP 0.01uF 5% 16V
C246 1-104-553-11 FILM CHIP 0.015uF 5% 16V
C247 1-104-552-11 FILM CHIP 0.012uF 5% 16V
C248 1-104-553-11 FILM CHIP 0.015uF 5% 16V
C249 1-109-809-11 CAP-CHIP 2.2PF 0.25PF 100V
C250 1-110-500-11 ENCAPSULATED COMPONENT
C251 1-163-988-11 CERAMIC CHIP 180PF 5% 100V
C252 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C253 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C254 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C255 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C301 1-126-395-11 ELECT 22uF 20% 16V
C302 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
C303 1-124-779-00 ELECT CHIP 10uF 20% 16V
C304 1-126-395-11 ELECT 22uF 20% 16V
C305 1-104-847-11 TANTALUM CHIP 22uF 20% 4V
C306 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C307 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C308 1-107-686-11 TANTALUM CHIP 4.7uF 20% 16V
C309 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C310 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
C311 1-130-896-11 FILM 0.0082uF 5% 400V
C312 1-104-915-11 TANTALUM CHIP 2.2uF 20% 16V
C313 1-104-547-11 FILM CHIP 0.0047uF 5% 16V
C314 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C316 1-104-666-11 ELECT 220uF 20% 25V
C317 1-104-666-11 ELECT 220uF 20% 25V
C318 1-126-246-11 ELECT CHIP 220uF 20% 4V
C319 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C320 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C321 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C601 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C602 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C603 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C604 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C605 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-130-481-00 MYLAR 0.0068uF 5% 50V
C608 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C609 1-126-393-11 ELECT CHIP 33uF 20% 10V
C610 1-126-204-11 ELECT CHIP 47uF 20% 16V
C611 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C612 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C613 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C614 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C615 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C616 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C617 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN301 1-507-749-00 JACK, EXTENTION POWER (DC IN 6V)
< COMPOSITION CIRCUIT BLOCK >
CP101 1-235-317-11 FILTER, LOW PASS
CP102 1-235-318-11 FILTER, SP-SK
CP201 1-235-317-11 FILTER, LOW PASS
CP202 1-235-318-11 FILTER, SP-SK
CP304 1-464-183-21 CONVERTER UNIT, DC-DC
< DIODE >
D302 8-719-801-78 DIODE 1S2837-T1
D303 8-719-801-78 DIODE 1S2837-T1
< IC >
IC101 8-752-021-80 IC CX20218-T6
IC102 8-759-700-50 IC NJM386M-T1
IC201 8-752-021-80 IC CX20218-T6
IC202 8-759-700-50 IC NJM386M-T1
IC301 8-759-100-96 IC NJM4558M-TE2
IC302 8-759-100-96 IC NJM4558M-TE2
IC601 8-759-600-69 IC CX-069A
IC602 8-759-337-40 IC NJM2904V (TE2)
< JACK >
J301 1-507-794-31 JACK, SMALL TYPE (WITH SWITCH)
(MIC, PLUG IN POWER)
J302 1-507-929-41 JACK (LINE IN)
J303 1-507-929-41 JACK (LINE OUT)
J304 1-507-929-11 JACK (HEADPHONES)
< COIL >
L101 1-408-682-00 INDUCTOR 10mH
L102 1-408-930-00 INDUCTOR 33mH
L201 1-408-682-00 INDUCTOR 10mH
L202 1-408-930-00 INDUCTOR 33mH
L301 1-410-198-51 INDUCTOR 3.3uH
< TRANSISTOR >
Q101 8-729-021-87 TRANSISTOR 2SA1587-GRBL-TE85L
Q102 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q103 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q104 8-729-016-81 TRANSISTOR 2SC2412KLN-T146-S
Q105 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q106 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q107 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q108 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q109 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q201 8-729-021-87 TRANSISTOR 2SA1587-GRBL-TE85L
Q202 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q203 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q204 8-729-016-81 TRANSISTOR 2SC2412KLN-T146-S
Q205 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q206 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q207 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q208 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q209 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q301 8-729-120-28 TRANSISTOR 2SC1623-T1L6
