Page #45 background imageLoading...
Page #45 background image
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
10
WM-D6C/TC-D6C
Q302 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q303 8-729-162-45 TRANSISTOR 2SB624-T1BV5
Q304 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q305 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q306 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q307 8-729-141-75 TRANSISTOR 2SD596T1-DV345
Q308 8-729-162-45 TRANSISTOR 2SB624-T1BV5
Q309 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q310 8-729-420-50 TRANSISTOR UN5215- (TX)
Q311 8-729-420-50 TRANSISTOR UN5215- (TX)
Q312 8-729-420-50 TRANSISTOR UN5215- (TX)
Q313 8-729-420-50 TRANSISTOR UN5215- (TX)
Q314 8-729-420-50 TRANSISTOR UN5215- (TX)
Q315 8-729-420-50 TRANSISTOR UN5215- (TX)
Q316 8-729-420-50 TRANSISTOR UN5215- (TX)
Q317 8-729-420-50 TRANSISTOR UN5215- (TX)
Q318 8-729-420-50 TRANSISTOR UN5215- (TX)
Q319 8-729-420-50 TRANSISTOR UN5215- (TX)
Q320 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q321 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q322 8-729-216-22 TRANSISTOR 2SA812-T1M6
Q601 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q602 8-729-216-22 TRANSISTOR 2SA812-T1M6
Q603 8-729-109-44 TRANSISTOR 2SK209Y-TE85L
Q604 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q605 8-729-101-07 TRANSISTOR 2SB798-T1DK
< RESISTOR >
R101 1-216-845-11 METAL CHIP 100K 5% 1/16W
R102 1-216-838-11 METAL CHIP 27K 5% 1/16W
R103 1-216-833-11 METAL CHIP 10K 5% 1/16W
R104 1-216-029-00 METAL CHIP 150 5% 1/10W
R105 1-216-839-11 METAL CHIP 33K 5% 1/16W
R106 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R107 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R108 1-216-837-11 METAL CHIP 22K 5% 1/16W
R109 1-216-113-00 METAL CHIP 470K 5% 1/10W
R110 1-216-857-11 METAL CHIP 1M 5% 1/16W
R111 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R112 1-216-047-00 RES-CHIP 820 5% 1/10W
R113 1-216-095-00 METAL CHIP 82K 5% 1/10W
R114 1-216-697-11 METAL CHIP 82K 0.5% 1/10W
R115 1-216-027-00 METAL CHIP 120 5% 1/10W
R116 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/16W
R118 1-216-815-11 METAL CHIP 330 5% 1/16W
R119 1-216-075-00 METAL CHIP 12K 5% 1/10W
R120 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R121 1-216-846-11 METAL CHIP 120K 5% 1/16W
R122 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R123 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R124 1-216-075-00 METAL CHIP 12K 5% 1/10W
R125 1-216-079-00 METAL CHIP 18K 5% 1/10W
R126 1-216-113-00 METAL CHIP 470K 5% 1/10W
R127 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R128 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R129 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
R130 1-216-092-00 RES-CHIP 62K 5% 1/10W
R131 1-216-056-00 RES-CHIP 2K 5% 1/10W
R132 1-216-839-11 METAL CHIP 33K 5% 1/16W
R133 1-216-056-00 RES-CHIP 2K 5% 1/10W
R134 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R135 1-216-090-00 METAL CHIP 51K 5% 1/10W
R136 1-216-109-00 METAL CHIP 330K 5% 1/10W
R137 1-216-821-11 METAL CHIP 1K 5% 1/16W
R138 1-216-076-00 METAL CHIP 13K 5% 1/10W
R139 1-216-076-00 METAL CHIP 13K 5% 1/10W
R140 1-216-839-11 METAL CHIP 33K 5% 1/16W
R141 1-216-045-00 METAL CHIP 680 5% 1/10W
R142 1-216-056-00 RES-CHIP 2K 5% 1/10W
R143 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R144 1-216-841-11 METAL CHIP 47K 5% 1/16W
R145 1-216-842-11 METAL CHIP 56K 5% 1/16W
R146 1-216-833-11 METAL CHIP 10K 5% 1/16W
R147 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R148 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R149 1-216-835-11 METAL CHIP 15K 5% 1/16W
R150 1-216-841-11 METAL CHIP 47K 5% 1/16W
R151 1-216-039-00 METAL CHIP 390 5% 1/10W
R152 1-216-005-00 METAL CHIP 15 5% 1/10W
(EXCEPT French)
R152 1-216-042-00 METAL CHIP 510 5% 1/10W
(French)
R154 1-218-763-11 RES-CHIP 300K 5% 1/10W
R155 1-216-839-11 METAL CHIP 33K 5% 1/16W
R156 1-216-842-11 METAL CHIP 56K 5% 1/16W
R157 1-216-845-11 METAL CHIP 100K 5% 1/16W
R158 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R159 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R160 1-216-833-11 METAL CHIP 10K 5% 1/16W
R161 1-202-924-11 RES-CHIP 240 5% 1/16W
R162 1-216-812-11 METAL CHIP 180 5% 1/16W
R163 1-216-035-00 METAL CHIP 270 5% 1/10W
R164 1-216-837-11 METAL CHIP 22K 5% 1/16W
R165 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R166 1-216-072-00 METAL CHIP 9.1K 5% 1/10W
R167 1-216-845-11 METAL CHIP 100K 5% 1/16W
R168 1-216-095-00 METAL CHIP 82K 5% 1/10W
R169 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R170 1-216-857-11 METAL CHIP 1M 5% 1/16W
R171 1-216-821-11 METAL CHIP 1K 5% 1/16W
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R201 1-216-845-11 METAL CHIP 100K 5% 1/16W
R202 1-216-838-11 METAL CHIP 27K 5% 1/16W
R203 1-216-833-11 METAL CHIP 10K 5% 1/16W
R204 1-216-029-00 METAL CHIP 150 5% 1/10W
R205 1-216-839-11 METAL CHIP 33K 5% 1/16W
R206 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R207 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R208 1-216-837-11 METAL CHIP 22K 5% 1/16W
R209 1-216-113-00 METAL CHIP 470K 5% 1/10W
R210 1-216-857-11 METAL CHIP 1M 5% 1/16W
R211 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R212 1-216-047-00 RES-CHIP 820 5% 1/10W
R213 1-216-095-00 METAL CHIP 82K 5% 1/10W
