3 3-704-197-01 SCREW (IB LOCK) 3 3-704-197-01 SCREW 1.4X1.6 (S) (for SILVER, BLUE,
GRAY)
(EX650/EX652: EA/EX654: EXCEPT EA)
3 3-704-197-03 SCREW 1.4X1.6 (B) (for BLACK)
(EX650/EX652: EXCEPT EA/EX654: EA)
11 3-015-995-01 SPACER (CASSETTE)
12 3-389-523-15 SCREW 1.4X2 (S) (for SILVER, BLUE,
GRAY)
(EX650/EX652: EA/EX654: EXCEPT EA)
12 3-389-523-16 SCREW 1.4X2 (B) (for BLACK)
(EX650/EX652: EXCEPT EA/EX654: EA)
CORRECTION-1
Correct your service manual as shown below.
WM-EX650/EX652/EX654
AEP Model
WM-EX650/EX652/EX654
UK Model
E Model
WM-EX652/EX654
Page INCORRECT CORRECT
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
24
! : indicates corrected portion.
Sony Corporation
Personal A&V Products Company9-923-154-91
97J0577-1
Printed in Japan © 1997. 10
Published by Quality Engineering Dept.
(Shibaura)
(SPM-97023)
