– 14 –
2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
MAIN
A-3061-503-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-164-473-11 CERAMIC CHIP 820PF 10% 50V
C102 1-164-473-11 CERAMIC CHIP 820PF 10% 50V
C103 1-128-024-11 ELECT CHIP 4.7uF 20% 10V
C104 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C105 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C106 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C108 1-128-014-11 ELECT CHIP 10uF 20% 4V
C109 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C111 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C112 1-115-156-11 CERAMIC CHIP 1uF 10V
C113 1-115-156-11 CERAMIC CHIP 1uF 10V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C117 1-115-156-11 CERAMIC CHIP 1uF 10V
C201 1-164-473-11 CERAMIC CHIP 820PF 10% 50V
C202 1-164-473-11 CERAMIC CHIP 820PF 10% 50V
C203 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C204 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C205 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C208 1-128-014-11 ELECT CHIP 10uF 20% 4V
C209 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C212 1-115-156-11 CERAMIC CHIP 1uF 10V
C213 1-115-156-11 CERAMIC CHIP 1uF 10V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C216 1-115-156-11 CERAMIC CHIP 1uF 10V
C217 1-115-156-11 CERAMIC CHIP 1uF 10V
C220 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C301 1-135-316-11 TANTALUM CHIP 22uF 20% 2.5V
C302 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C303 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C304 1-128-024-11 ELECT CHIP 4.7uF 20% 10V
C305 1-135-316-11 TANTALUM CHIP 22uF 20% 2.5V
C306 1-110-423-11 ELECT CHIP 2.2uF 20% 25V
C307 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C308 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C309 1-115-156-11 CERAMIC CHIP 1uF 10V
C310 1-115-156-11 CERAMIC CHIP 1uF 10V
C311 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C312 1-109-935-11 TANTALUM CHIP 4.7uF 20% 4V
C313 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C314 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C315 1-115-156-11 CERAMIC CHIP 1uF 10V
C316 1-115-156-11 CERAMIC CHIP 1uF 10V
C317 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C318 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C319 1-107-688-11 TANTALUM CHIP 1.5uF 20% 10V
C320 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C321 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C323 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C327 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C501 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C502 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C601 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(SUFFIX-21)
C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(SUFFIX-14)
C602 1-113-619-11 CERAMIC CHIP 0.47uF 10V
(SUFIFX-21)
C602 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(SUFFIX-14)
C603 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(SUFFIX-21)
C603 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(SUFFIX-14)
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(SUFFIX-14)
C604 1-135-221-11 TANTALUM CHIP 3.3uF 20% 4V
(SUFFIX-21)
