– 16 –
MAIN
R306 1-216-793-11 RES, CHIP 4.7 (1608)
R307 1-216-847-11 METAL CHIP 150K 5% 1/16W
R308 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R309 1-216-841-11 METAL CHIP 47K 5% 1/16W
R501 1-216-849-11 METAL CHIP 220K 5% 1/16W
R502 1-216-833-11 METAL CHIP 10K 5% 1/16W
R601 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(SUFFIX-21)
R602 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(SUFFIX-21)
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(SUFFIX-21)
R604 1-216-809-11 METAL CHIP 100 5% 1/16W
(SUFFIX-21)
R604 1-216-817-11 METAL CHIP 470 5% 1/16W
(SUFFIX-14)
R605 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
(SUFFIX-14)
R605 1-216-837-11 METAL CHIP 22K 5% 1/16W
(SUFFIX-21)
R606 1-216-809-11 METAL CHIP 100 5% 1/16W
(SUFFIX-14)
R607 1-216-837-11 METAL CHIP 22K 5% 1/16W
(SUFFIX-14)
R701 1-216-817-11 METAL CHIP 470 5% 1/16W
R702 1-216-851-11 METAL CHIP 330K 5% 1/16W
R703 1-216-849-11 METAL CHIP 220K 5% 1/16W
R704 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R705 1-216-849-11 METAL CHIP 220K 5% 1/16W
R706 1-216-849-11 METAL CHIP 220K 5% 1/16W
R707 1-218-870-11 RES, CHIP 9.1K (1608)
R708 1-216-851-11 METAL CHIP 330K 5% 1/16W
R709 1-216-845-11 METAL CHIP 100K 5% 1/16W
R710 1-218-836-11 RES, CHIP 360 (1608)
R711 1-218-845-11 RES, CHIP 820 (1608)
R712 1-218-847-11 RES, CHIP 1.0K (1608)
R713 1-218-849-11 RES, CHIP 1.2K (1608)
R714 1-218-866-11 RES, CHIP 6.2K (1608)
R715 1-216-849-11 METAL CHIP 220K 5% 1/16W
R716 1-216-849-11 METAL CHIP 220K 5% 1/16W
R717 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R719 1-216-821-11 METAL CHIP 1K 5% 1/16W
R720 1-216-162-00 RES, CHIP 33 (3216)
R721 1-216-162-00 RES, CHIP 33 (3216)
R722 1-216-817-11 METAL CHIP 470 5% 1/16W
R723 1-216-817-11 METAL CHIP 470 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB301 1-233-872-21 RES, NETWORK (CHIP TYPE)(3216)
RB601 1-233-873-21 RES, NETWORK (CHIP TYPE)(3216)
(SUFFIX-14)
RB602 1-233-576-11 RES, CHIP NETWORK 100
RB701 1-233-418-11 RES, CHIP NETWORK 3.3K (3216)
< VARIABLE RESISTOR >
RV301 1-225-342-11 RES, VAR, CARBON 10K/10K (VOLUME )
RV601 1-223-576-11 RES, ADJ, METAL GLAZE 2.2K (SUFFIX-14)
RV601 1-223-921-11 RES, ADJ, METAL GLAZE 4.7K (SUFFIX-21)
< SWITCH >
S701 1-762-970-21 SWITCH, PUSH (1 KEY)(CASSETTE HOLDER)
S702 1-572-581-11 SWITCH, SLIDE (DIRECTION)
S703 1-572-922-11 SWITCH, SLIDE (C HOLD)
S704 1-692-453-11 SWITCH, KEY BOARD (p)
S705 1-692-453-11 SWITCH, KEY BOARD (9(REPEAT)
S706 1-692-453-11 SWITCH, KEY BOARD (FF)
S707 1-692-453-11 SWITCH, KEY BOARD (REW)
S708 1-692-453-11 SWITCH, KEY BOARD (FUNCTION)
< THERMISTOR (POSITIVE) >
THP601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X701 1-760-872-11 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Former Type: 1-664-732-11
New Type: 1-664-732-14 or 1-664-732-21
Sony Corporation
Personal A&V Products Company
97K0574-1
Printed in Japan © 1997. 11
Published by Quality Engineering Dept.
(Shibaura)
9-923-154-81
WM-EX650/EX652/EX654
