Sony WM-EX651 - Ornament (Open) Assy; Holder (FS) Assy

9
WM-EX651
3-7. ORNAMENT (OPEN) ASSY
3-8. HOLDER (FS) ASSY
1 two claws
5 ornament (open) assy
3 boss
4 two claws
2 claw
9 Remove soldering from
six head flexible boards.
0 Remove the holder (FS)
assy in the direction of
the arrow.
8 shielded sheet
1 two screws
(ib lock)
3 lock lever (B)
2 shaft
7 bracket (cassette) assy
6 shaft
4 screw (M1.4
)
5 shaft
