Sony WM-EX660 User Manual

– 31 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
CN301 1-766-336-21 CONNECTOR, FFC/FPC 6P
< DIODE >
D101 8-719-423-35 DIODE MA8120-H
D201 8-719-423-35 DIODE MA8120-H
D301 8-719-423-35 DIODE MA8120-H
D501 8-719-049-09 DIODE 1SS367-T3SONY
D701 8-719-404-49 DIODE MA111
D702 8-719-049-09 DIODE 1SS367-T3SONY
D703 8-719-067-79 LED CL-170HR-CD-T-AB (BATT)
D704 8-719-067-79 LED CL-170HR-CD-T-AB (SOUND GRV)
D705 8-719-067-79 LED CL-170HR-CD-T-AB (SOUND MB)
D706 8-719-067-79 LED CL-170HR-CD-T-AB (BL SKIP)
D707 8-719-067-79 LED CL-170HR-CD-T-AB (AVLS)
D708 8-719-067-79 LED CL-170HR-CD-T-AB (a NR)
D709 8-719-423-35 DIODE MA8120-H
< FERRITE BEAD >
FB101 1-414-235-11 INDUCTOR, FERRITE BEAD (EXCEPT French)
FB201 1-414-235-11 INDUCTOR, FERRITE BEAD (EXCEPT French)
FB301 1-414-235-11 INDUCTOR, FERRITE BEAD
< IC >
IC301 8-759-359-76 IC TA2072AF
IC601 8-759-356-46 IC MM1279XVBE
IC701 8-759-479-49 IC MSM6576-83GS-K
IC702 8-759-280-85 IC PST9010NL
IC703 8-759-430-08 IC PST9008NL
IC704 8-759-469-63 IC S-81215SGUP-DQK-T1
< JACK >
J701 1-778-930-21 JACK 7P (2 REMOTE)
< CHIP CONDUCTOR >
JC802 1-216-864-11 METAL CHIP 0 5% 1/16W
< PHOTO INTERRUPTER >
PH701 8-719-988-15 PHTO REFLECTOR PR-11-C
< TRANSISTOR >
Q301 8-729-022-66 TRANSISTOR XN1210-TX
Q302 8-729-422-39 TRANSISTOR XN4404
Q303 8-729-403-17 TRANSISTOR XN1215
Q304 8-729-230-72 TRANSISTOR 2SA1362YG
Q305 8-729-421-23 TRANSISTOR XN1216
Q501 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q502 8-729-115-28 TRANSISTOR BN1L3Z-K
Q503 8-729-403-17 TRANSISTOR XN1215
Q504 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q601 8-729-403-42 TRANSISTOR XN1401
Q602 8-729-402-84 TRANSISTOR XN4601
Q701 8-729-422-18 TRANSISTOR XN4315
Q702 8-729-421-26 TRANSISTOR UN5216
Q703 8-729-230-72 TRANSISTOR 2SA1362YG
Q704 8-729-422-51 TRANSISTOR UN5110-QRS
Q705 8-729-402-42 TRANSISTOR UN5213
Q706 8-729-403-17 TRANSISTOR XN1215
Q707 8-729-403-17 TRANSISTOR XN1215
Q708 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q709 8-729-030-53 TRANSISTOR MSD1819A-RT1
Q710 8-729-421-26 TRANSISTOR UN5216
Q711 8-729-230-72 TRANSISTOR 2SA1362YG
Q712 8-729-422-51 TRANSISTOR UN5110-QRS
< RESISTOR >
R101 1-216-812-11 METAL CHIP 180 5% 1/16W
R102 1-216-847-11 METAL CHIP 150K 5% 1/16W
R103 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R104 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R108 1-218-270-11 RES, CHIP 1.1K (1608)
R109 1-216-834-11 METAL CHIP 12K 5% 1/16W
R110 1-216-852-11 METAL CHIP 390K 5% 1/16W
R111 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R112 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R113 1-216-809-11 METAL CHIP 100 5% 1/16W
R114 1-216-840-11 METAL CHIP 39K 5% 1/16W
R115 1-216-793-11 RES, CHIP 4.7 (1608)
R151 1-220-370-91 RES, CHIP 62 (French)
R152 1-220-370-91 RES, CHIP 62 (French)
R201 1-216-812-11 METAL CHIP 180 5% 1/16W
R202 1-216-847-11 METAL CHIP 150K 5% 1/16W
R203 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R204 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R205 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R208 1-218-270-11 RES, CHIP 1.1K (1608)
R209 1-216-834-11 METAL CHIP 12K 5% 1/16W
R210 1-216-852-11 METAL CHIP 390K 5% 1/16W
R211 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R212 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R213 1-216-809-11 METAL CHIP 100 5% 1/16W
R214 1-216-840-11 METAL CHIP 39K 5% 1/16W
R215 1-216-793-11 RES, CHIP 4.7 (1608)
R301 1-218-891-11 RES, CHIP 68K (1608)
R302 1-216-839-11 METAL CHIP 33K 5% 1/16W
R303 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R304 1-218-295-11 RES, CHIP 43K (1608)
R305 1-216-821-11 METAL CHIP 1K 5% 1/16W
R306 1-216-793-11 RES, CHIP 4.7 (1608)
R307 1-216-847-11 METAL CHIP 150K 5% 1/16W
R308 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R309 1-216-841-11 METAL CHIP 47K 5% 1/16W
R501 1-216-849-11 METAL CHIP 220K 5% 1/16W
R502 1-216-833-11 METAL CHIP 10K 5% 1/16W
R604 1-216-817-11 METAL CHIP 470 5% 1/16W
R605 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R606 1-216-809-11 METAL CHIP 100 5% 1/16W
R607 1-216-837-11 METAL CHIP 22K 5% 1/16W
R701 1-216-817-11 METAL CHIP 470 5% 1/16W
R702 1-216-851-11 METAL CHIP 330K 5% 1/16W
R703 1-216-849-11 METAL CHIP 220K 5% 1/16W
R704 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R705 1-216-849-11 METAL CHIP 220K 5% 1/16W
MAIN
