– 32 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R706 1-216-849-11 METAL CHIP 220K 5% 1/16W
R707 1-218-870-11 RES, CHIP 9.1K (1608)
R708 1-216-851-11 METAL CHIP 330K 5% 1/16W
R709 1-216-845-11 METAL CHIP 100K 5% 1/16W
R710 1-218-836-11 RES, CHIP 360 (1608)
R711 1-218-845-11 RES, CHIP 820 (1608)
R712 1-218-847-11 RES, CHIP 1.0K (1608)
R713 1-218-849-11 RES, CHIP 1.2K (1608)
R714 1-218-866-11 RES, CHIP 6.2K (1608)
R715 1-216-849-11 METAL CHIP 220K 5% 1/16W
R716 1-216-849-11 METAL CHIP 220K 5% 1/16W
R717 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R719 1-216-821-11 METAL CHIP 1K 5% 1/16W
R720 1-216-162-00 RES, CHIP 33 (3216)
R721 1-216-162-00 RES, CHIP 33 (3216)
R722 1-216-817-11 METAL CHIP 470 5% 1/16W
R723 1-216-817-11 METAL CHIP 470 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB301 1-233-872-21 RES, NETWORK (CHIP TYPE)(3216)
RB601 1-233-873-21 RES, NETWORK (CHIP TYPE)(3216)
RB602 1-233-576-11 RES, CHIP NETWORK 100
RB701 1-233-418-11 RES, CHIP NETWORK 3.3K (3216)
< VARIABLE RESISTOR >
RV301 1-225-342-11 RES, VAR, CARBON 10K/10K (VOLUME )
RV601 1-223-576-11 RES, ADJ, METAL GLAZE 2.2K
< SWITCH >
S701 1-762-970-21 SWITCH, PUSH (1 KEY)(CASSETTE HOLDER)
S702 1-572-581-11 SWITCH, SLIDE (DIRECTION)
S703 1-572-922-11 SWITCH, SLIDE (C HOLD)
S704 1-692-453-11 SWITCH, KEY BOARD (p)
S705 1-692-453-11 SWITCH, KEY BOARD (9(REPEAT)
S706 1-692-453-11 SWITCH, KEY BOARD (FF)
S707 1-692-453-11 SWITCH, KEY BOARD (REW)
S708 1-692-453-11 SWITCH, KEY BOARD (FUNCTION)
< THERMISTOR (POSITIVE) >
THP601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X701 1-760-872-11 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
MISCELLANEOUS
***************
HP901 1-500-420-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-698-885-21 MOTOR (CAPSTAN/REEL)
PM901 1-454-674-31 SOLENOID, PLUNGER
S901 1-762-793-22 SWITCH, LEAF (ATS)
************************************************************
MAIN
∑
ACCESSORIES & PACKING MATERIALS
********************************
1-475-181-11 REMOTE CONTROL UNIT (RM-WME654)
(EX660: French/EX662)
1-505-535-11 HEADPHONE (WITH REMOTE CONTROL)
(EX660/EX662: French)
! 1-528-252-21 BATTERY CHARGER (BC-7S) (UK)
1-528-543-11 BATTERY, NICKEL CADMIUM (NC-6WM)
(EX662: E, 9E, Saudi Arabia, Korean)
1-528-543-22 BATTERY, NI-CD (NC-6WM)
! 1-528-644-11 CHARGER, BATTERY (BC-7DT2) (EX662: E, 9E)
! 1-528-661-11 BATTERY CHARGER (BC-7DR)
(EX662: Korean)
! 1-528-744-21 BATTERY CHARGER (BC-7DY) (EX660: AEP,
French/EX662: AEP, French, Saudi Arabia)
1-569-007-11 ADAPTOR, CONVERSION 2P (EX662: E, 9E)
1-759-213-11 CASE, BATTERY
3-008-521-01 CASE, BATTERY CHARGE
3-860-971-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN) (AEP, French)
3-860-971-21 MANUAL, INSTRUCTION (DUTCH, SWEDISH,
PORTUGUESE) (AEP)
3-860-971-31 MANUAL, INSTRUCTION (SPANISH, ITALIAN,
DANISH) (AEP)
3-860-971-41 MANUAL, INSTRUCTION (ENGLISH, KOREAN,
CHINESE) (E)
3-860-971-51 MANUAL, INSTRUCTION (ENGLISH, KOREAN,
CHINESE) (9E)
3-918-937-01 CASE, CARRYING
8-953-171-91 HEADPHONE MDR-ED136MP/K1 SET
(EX660: French/EX662: EXCEPT French)
WM-EX660/EX662
Sony Corporation
Personal A&V Products Company
9-923-322-11
98B0574-1
Printed in Japan © 1998. 2
Published by Quarity Engineering Dept.
(Shibaura)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
