25
WM-GX400
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C277 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C278 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C279 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C280 1-115-156-11 CERAMIC CHIP 1uF 10V
C282 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C333 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C334 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C335 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C336 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C337 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C338 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C339 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C340 1-115-156-11 CERAMIC CHIP 1uF 10V
C341 1-115-156-11 CERAMIC CHIP 1uF 10V
C352 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C354 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C355 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C356 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C357 1-115-156-11 CERAMIC CHIP 1uF 10V
C358 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C371 1-124-584-00 ELECT 100uF 20% 10V
C374 1-115-156-11 CERAMIC CHIP 1uF 10V
C375 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C402 1-115-156-11 CERAMIC CHIP 1uF 10V
C403 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C404 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C405 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C406 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C407 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C408 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C409 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C410 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C502 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C503 1-126-518-11 ELECT 470uF 20% 4V
C504 1-124-434-00 ELECT 220uF 20% 4V
C602 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C603 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C604 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C605 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C606 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C607 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C608 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C609 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
<CONNECTOR>
CN301 1-573-362-11 CONNECTOR, FFC/FPC 22P
CN302 1-573-931-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN303 1-573-349-21 CONNECTOR, FFC/FPC 9P
<TRIMMER>
CT1 1-141-422-11 CAP, ADJ 10PF (AM TRACKING)
<DIODE>
D1 8-719-076-70 DIODE KV1520TL
D2 8-719-076-71 DIODE KV1471ETR
D4 8-719-076-71 DIODE KV1471ETR
D401 8-719-073-01 DIODE MA111-(K8).S0
D402 8-719-420-87 DIODE MA8130
D403 8-719-049-09 DIODE 1SS367-T3SONY
D406 8-719-988-61 DIODE 1SS355TE-17
D501 8-719-049-09 DIODE 1SS367-T3SONY
<FERRITE BEAD>
FB101 1-414-760-21 FERRITE 0uH
FB201 1-414-760-21 FERRITE 0uH
FB301 1-414-813-11 FERRITE 0uH
FB302 1-414-760-21 FERRITE 0uH
FB303 1-414-760-21 FERRITE 0uH
<IC>
IC1 8-752-073-35 IC CXA1960Q
IC101 8-759-701-02 IC NJM2073M
IC201 8-759-701-02 IC NJM2073M
IC301 8-759-638-51 IC LB1979VL-TLM
IC302 8-752-089-40 IC CXA2500N-T4
<JACK>
J301 1-815-259-11 JACK (i)
J302 1-774-321-32 JACK (SMALL TYPE) (MIC (PLUG IN POWER))
J501 1-794-615-11 JACK,DC(POLARITY UNIFIED TYPE)(DC IN 3V)
<JUMPER RESISTOR>
JC2 1-216-864-91 SHORT 0 (CND,5E)
JC3 1-216-864-91 SHORT 0
<COIL>
L3 1-754-170-11 ANTENNA, FERRITE-ROD
L4 1-424-730-21 FM RF COIL (FM TRACKING)
L6 1-419-135-21 INDUCTOR 27nH
L7 1-419-984-11 COIL (AM OSC) (AM TRACKING)
L401 1-414-521-21 INDUCTOR 10uH
<TRANSISTOR>
Q1 8-729-054-77 TRANSISTOR 2SC4098-T106-PQ (CND,5E)
Q1 8-729-230-63 TRANSISTOR 2SC4116-YG (EXCEPT CND,5E)
Q2 8-729-014-12 TRANSISTOR RN1311-TE85L
(EXCEPT CND,5E)
Q3 8-729-423-52 TRANSISTOR 2SC3931-C
Q101 8-729-013-37 TRANSISTOR 2SC4213-AB-TE85L
Q201 8-729-013-37 TRANSISTOR 2SC4213-AB-TE85L
Q301 8-729-028-76 TRANSISTOR DTA114YUA-T106
Q302 8-729-230-63 TRANSISTOR 2SC4116-YG
Q307 8-729-230-60 TRANSISTOR 2SA1586-YG
Q308 8-729-014-12 TRANSISTOR RN1311-TE85L
Q334 8-729-141-75 TRANSISTOR 2SD596DV345
Q335 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q336 8-729-230-63 TRANSISTOR 2SC4116-YG
Q354 8-729-014-12 TRANSISTOR RN1311-TE85L
Q355 8-729-230-63 TRANSISTOR 2SC4116-YG
Q356 8-729-230-60 TRANSISTOR 2SA1586-YG
Q371 8-729-028-99 TRANSISTOR DTC114YUA-T106
Q372 8-729-230-63 TRANSISTOR 2SC4116-YG
Q373 8-729-230-72 TRANSISTOR 2SA1362YG
