27
WM-GX400
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R343 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R344 1-216-864-91 SHORT 0
R352 1-216-821-11 METAL CHIP 1K 5% 1/16W
R353 1-216-833-11 METAL CHIP 10K 5% 1/16W
R356 1-216-833-11 METAL CHIP 10K 5% 1/16W
R357 1-216-841-11 METAL CHIP 47K 5% 1/16W
R358 1-216-821-11 METAL CHIP 1K 5% 1/16W
R359 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R360 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R371 1-216-833-11 METAL CHIP 10K 5% 1/16W
R372 1-216-847-11 METAL CHIP 150K 5% 1/16W
R373 1-216-864-91 SHORT 0
R374 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R375 1-216-857-11 METAL CHIP 1M 5% 1/16W
R376 1-216-857-11 METAL CHIP 1M 5% 1/16W
R377 1-216-817-11 METAL CHIP 470 5% 1/16W
R378 1-216-821-11 METAL CHIP 1K 5% 1/16W
R401 1-216-821-11 METAL CHIP 1K 5% 1/16W
R402 1-216-845-11 METAL CHIP 100K 5% 1/16W
R403 1-216-801-11 METAL CHIP 22 5% 1/16W
R404 1-216-841-11 METAL CHIP 47K 5% 1/16W
R441 1-216-821-11 METAL CHIP 1K 5% 1/16W
R501 1-216-819-11 METAL CHIP 680 5% 1/16W
R502 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R503 1-216-833-11 METAL CHIP 10K 5% 1/16W
R504 1-216-847-11 METAL CHIP 150K 5% 1/16W
R505 1-216-845-11 METAL CHIP 100K 5% 1/16W
R601 1-216-821-11 METAL CHIP 1K 5% 1/16W
R602 1-216-857-11 METAL CHIP 1M 5% 1/16W
R603 1-216-857-11 METAL CHIP 1M 5% 1/16W
R604 1-216-857-11 METAL CHIP 1M 5% 1/16W
R605 1-216-821-11 METAL CHIP 1K 5% 1/16W
R606 1-216-864-91 SHORT 0
R607 1-216-845-11 METAL CHIP 100K 5% 1/16W
R608 1-216-864-91 SHORT 0
R609 1-216-833-11 METAL CHIP 10K 5% 1/16W
R610 1-216-841-11 METAL CHIP 47K 5% 1/16W
R611 1-216-809-11 METAL CHIP 100 5% 1/16W
R612 1-216-841-11 METAL CHIP 47K 5% 1/16W
R613 1-216-809-11 METAL CHIP 100 5% 1/16W
R614 1-216-839-11 METAL CHIP 33K 5% 1/16W
<VARIABLE RESISTOR>
RV1 1-223-258-11 RES, CARBON ADJ VAR 4.7K (FM VCO)
RV2 1-223-998-21 RES, CARBON ADJ VAR 100K (AM IF)
RV301 1-227-319-21 RES, VAR (VOLUME)
RV601 1-223-258-11 RES, CARBON ADJ VAR 4.7K
(TAPE SPEED 2.4cm/s)
RV602 1-223-258-11 RES, CARBON ADJ VAR 4.7K
(TAPE SPEED 4.8cm/s)
<SWITCH>
S301 1-762-081-11 SWITCH, SLIDE(FWD/REV)
S302 1-762-081-11 SWITCH, SLIDE(REC/PB)
S303 1-572-922-11 SWITCH, SLIDE (PAUSE)
S601 1-572-688-11 SWITCH, PUSH (1 KEY) (TAPE)
<TRANSFORMER>
T331 1-433-286-23 TRANSFORMER, BIAS OSCILLATION
T401 1-449-021-21 TRANSFORMER, DC/DC CONVERTER
<THERMISTOR>
TH601 1-810-794-11 THERMISTOR, POSITIVE
************************************************************
* A-3021-365-A DISPLAY BOARD, COMPLETE (AEP,FR,CH,EA)
* A-3021-366-A DISPLAY BOARD, COMPLETE (E,9E,JEW)
* A-3021-368-A DISPLAY BOARD, COMPLETE (CND,5E)
************************
<CAPACITOR>
C702 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C704 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C705 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C706 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C708 1-115-156-11 CERAMIC CHIP 1uF 10V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C712 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C713 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C715 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C717 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C718 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C719 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C721 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C722 1-115-156-11 CERAMIC CHIP 1uF 10V
C724 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C726 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C727 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C732 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C750 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C751 1-115-156-11 CERAMIC CHIP 1uF 10V
C752 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
<CONNECTOR>
CN701 1-573-931-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN702 1-573-362-11 CONNECTOR, FFC/FPC 22P
<IC>
IC701 6-800-115-01 IC LC72349W-9A27
IC702 8-759-457-70 IC XC62RP1602MR
<JUMPER RESISTOR>
JC701 1-216-864-91 SHORT 0
JC702 1-216-864-91 SHORT 0
JC703 1-216-864-91 SHORT 0
<COIL>
L702 1-412-995-21 INDUCTOR 22uH
<RESISTOOR>
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
