(A) Blu-ray/DVD player (same as connecting a cable/satellite box)
(B) Analog Extension cable (supplied)
(C) RCA Cable (not supplied)
Whether the Analog Extension cable is supplied depends on your model/region/country.
Cable that connects to the video input jack
The 3.5 mm jack of the Analog Extension Cable has 4 poles.
(A) 3.5 mm
(B) Left for Audio signal.
(C) Video signal.
(D) Ground.
(E) Right for Audio signal.
